• Vaccine Storage Capacity as per Std. PQS load : 18 Litres.
  • Gross Storage Capacity : 22.21 Litres.
  • Weight Fully Loaded : 45.86 Kgs.
  • Weight Empty (with empty ice pack) : 21.78 Kgs.
  • External surface material : LLDPE*
  • Internal lining material : LLDPE*
  • Insulation material : CFC free Polyurethane
  • Insulation thickness : 100 mm
  • External Dimensions(LxWxH) : 70.0x61.0x51.0 cms.
  • Internal Dimensions(LxWxH) : 53.0x37.5x30.5 cms.
  • Vaccine Storage Dimension : 45.5x30.5x16.0 cms.
  • Lid Type and Fixings : Hinged
  • Number of Ice Packs required : 50.
  • Number of Ice Packs supplied : 50.
  • Ice-pack type compliant with PQS E0S/IP01.1 : 0.3 L.
  • Volume of Ice Pack : 0.30 Litres.
  • Min. Cold life Req. : 96 hrs.
  • Conforming to WHO PQS Ref. No. : E04/CB01.1.
  • Cold Life without openings at +43°C : 126 hrs. 32 mins.
  • Warm Life at -20°C : 44 hrs. 48 mins.
  • Cool Life at +43°C : 28 hrs. 05 mins.

  • *LLDPE - Linear Low Density Polyethylene
  • Vaccine Storage Capacity as per Std. PQS load : 18 Litres.
  • Gross Storage Capacity : 23.70 Litres.
  • Weight Fully Loaded : 47.86 Kgs.
  • Weight Empty (with empty ice pack) : 20.78 Kgs.
  • External surface material : LLDPE*
  • Internal lining material : LLDPE*
  • Insulation material : CFC free Polyurethane
  • Insulation thickness : 100 mm
  • External Dimensions(LxWxH) : 77.0x61.8x51.3 cms.
  • Internal Dimensions(LxWxH) : 52.9x37.5x30.0 cms.
  • Vaccine Storage Dimension : 44.2x29.3x18.3 cms.
  • Lid Type and Fixings : Hinged
  • Number of Ice Packs required : 31.
  • Number of Ice Packs supplied : 31.
  • Ice-pack type compliant with PQS E0S/IP01.1 : 0.6 L.
  • Volume of Ice Pack : 0.60 Litres.
  • Min. Cold life Req. : 96 hrs.
  • Conforming to WHO PQS Ref. No. : E04/CB01.1.
  • Cold Life without openings at +43°C : 145 hrs. 51 mins.
  • Warm Life at -20°C : 57 hrs. 42 mins.
  • Cool Life at +43°C : 34 hrs. 35 mins.

  • *LLDPE - Linear Low Density Polyethylene
  • Vaccine Storage Capacity as per Std. PQS load : 16 Litres.
  • Gross Storage Capacity : 22.91 Litres.
  • Weight Fully Loaded : 35 Kgs.
  • Weight Empty (with empty ice pack) : 14.50 Kgs.
  • External surface material : LLDPE*
  • Internal lining material : LLDPE*
  • Insulation material : CFC free Polyurethane
  • Insulation thickness : 65 mm
  • External Dimensions(LxWxH) : 64.5x64.0x35.0 cms.
  • Internal Dimensions(LxWxH) : 48.0x47.9x22.6 cms.
  • Vaccine Storage Dimension : 39.9x39.6x14.5 cms.
  • Lid Type and Fixings : Hinged
  • Number of Ice Packs required : 24.
  • Number of Ice Packs supplied : 24.
  • Ice-pack type compliant with PQS E0S/IP01.1 : 0.6 L.
  • Volume of Ice Pack : 0.6 Litres.
  • Min. Cold life Req. : 48 hrs.
  • Conforming to WHO PQS Ref. No. : E04/CB01.1.
  • Cold Life without openings at +43°C : 93 hrs. 33 mins.
  • Warm Life at -20°C : 31 hrs. 22 mins.
  • Cool Life at +43°C : 20 hrs. 42 mins.

  • *LLDPE - Linear Low Density Polyethylene
  • Vaccine Storage Capacity as per Std. PQS load : 16.0 Litres.
  • Gross Storage Capacity : 20.80 Litres.
  • Weight Fully Loaded : 34.42 Kgs.
  • Weight Empty (with empty ice pack) : 14.30 Kgs.
  • External surface material : LLDPE*
  • Internal lining material : LLDPE*
  • Insulation material : CFC free Polyurethane
  • Insulation thickness : 65 mm
  • External Dimensions(LxWxH) : 65.0x65.0x34.7 cms.
  • Internal Dimensions(LxWxH) : 47.8x48.1x22.5 cms.
  • Vaccine Storage Dimension : 40.1x40.6x12.78 cms.
  • Lid Type and Fixings : Hinged
  • Number of Ice Packs required : 32.
  • Number of Ice Packs supplied : 32.
  • Ice-pack type compliant with PQS E0S/IP01.1 : 0.4 L.
  • Volume of Ice Pack : 0.4 Litres.
  • Min. Cold life Req. : 48 hrs.
  • Conforming to WHO PQS Ref. No. : E04/CB01.1.
  • Cold Life without openings at +43°C : 80 hrs. 19 mins.
  • Warm Life at -20°C : 27 hrs. 44 mins.
  • Cool Life at +43°C : 18 hrs. 44 mins.

  • *LLDPE - Linear Low Density Polyethylene
  • Vaccine Storage Capacity as per Std. PQS load : 18 Litres.
  • Gross Storage Capacity : 21.70 Litres.
  • Weight Fully Loaded : 46.14 Kgs.
  • Weight Empty (with empty ice pack) : 21.34 Kgs.
  • External surface material : LLDPE*
  • Internal lining material : LLDPE*
  • Insulation material : CFC free Polyurethane
  • Insulation thickness : 100 mm
  • External Dimensions(LxWxH) : 77.0x61.0x51.0 cms.
  • Internal Dimensions(LxWxH) : 53.0x36.1x30.8x cms.
  • Vaccine Storage Dimension : 45.0x29.4x16.4 cms.
  • Lid Type and Fixings : Hinged
  • Number of Ice Packs required : 44.
  • Number of Ice Packs supplied : 44.
  • Ice-pack type compliant with PQS E0S/IP01.1 : 0.4 L.
  • Volume of Ice Pack : 0.4 Litres.
  • Min. Cold life Req. : 96 hrs.
  • Conforming to WHO PQS Ref. No. : E04/CB01.1.
  • Cold Life without openings at +43°C : 147 hrs. 14 mins.
  • Warm Life at -20°C : 52 hrs. 03 mins.
  • Cool Life at +43°C : 30 hrs. 39 mins.

  • *LLDPE - Linear Low Density Polyethylene
  • Vaccine Storage Capacity as per Std. PQS load : 6.0 Litres.
  • Gross Storage Capacity : 11.61 Litres.
  • Weight Fully Loaded : 25.40 Kgs.
  • Weight Empty (with empty ice pack) : 12.82 Kgs.
  • External surface material : LLDPE*
  • Internal lining material : LLDPE*
  • Insulation material : CFC free Polyurethane
  • Insulation thickness : 100 mm
  • External Dimensions(LxWxH) : 62.4x50.2x42.6 cms.
  • Internal Dimensions(LxWxH) : 40.3x28.2x21.1 cms.
  • Vaccine Storage Dimension : 33.0x21.2x16.6 cms.
  • Lid Type and Fixings : Hinged
  • Number of Ice Packs required : 26.
  • Number of Ice Packs supplied : 26.
  • Ice-pack type compliant with PQS E0S/IP01.1 : 0.4 L.
  • Volume of Ice Pack : 0.4 Litres.
  • Min. Cold life Req. : 96 hrs.
  • Conforming to WHO PQS Ref. No. : E04/CB01.1.
  • Cold Life without openings at +43°C : 132 hrs. 18 mins.
  • Warm Life at -20°C : 48 hrs. 41 mins.
  • Cool Life at +43°C : 29 hrs. 47 mins.

  • *LLDPE - Linear Low Density Polyethylene
