Obstetric Tables


HF3915 : Gynaecological Examination Couch

Standard Features:

  • Electrically operated Remote controlled backrest and height adjustment, Designed for Gynecology, Examination, Urology and simple surgical operations.
  • Size : L 2035mmXW600mmH (550mm- 850 mm).
  • Manual Trendelenburg (0-12°) by crank
  • Epoxy powder coated framework, Manual CPR -with handles on both side of backrest
  • Four castors - 125mmDiameter, Linear locking system
  • Height adjustable IV pole- 2 hooks ,urine bag holder
  • Easily removable Leg holders
  • Mattress : 28 Density Foam upholstery of fabric or artificial leather

HF3927 : Gynaecological Examination Table - 3 Function

Standard Features:

  • Electrically operated Remote controlled backrest, Leg rest and height adjustment, Suitable for Examination, Urological, Surgical operations and post operations.
  • Size : L 2160mmXW955mmH (525mm- 845 mm).
  • Removable ABS made Headrest, HPL Compact lying platform, ABS made lockable Side rails for Patient protection, with plastic protection bumpers ( dia 90 mm) on four side.
  • Electric Trendelenburg (0-12 °)/ Reverese Trendelenburg, Manual Trendelenburg (0-12 º) - by crank
  • Epoxy powder coated framework, Manual CPR -with handles on both side of back rest
  • Four castors - 125mmDiameter, with Central locking system
  • Height Adjustable Leg stirrups - recessed under beck section when not in use
  • Stainless Steel removable basin
  • Emergency battery backup.
  • Belt hook, accessories slots, urine bag holder.
  • Height adjustable IV pole- 2 hooks
  • Mattress : 28 Density Foam upholstery of fabric or artificial leather

HF1928 : Labour Delivery Recovery Bed
  • LDR bed is designed for all stages of labour, delivery and recovery.
  • Provides comfort and safety to the mother during the crucial time of child birth.
  • Adopts several positions of predelivery and various delivery positions such as lithotomy, sitting, squatting, lateral
  • Semi-prone and Trendelenberg. Complications and operations can be performed immediately without transferring patients.
  • If transfer is needed, this wheeled LDR bed can be lifted to a stretcher height.
  • The equipment of this bed is suitable for all birth and delivery processes except caesarean section and general anesthesia delivery.

Standard Features:

  • Electrically operated LDR bed with Embedded control panel on both side of guard rails for easy patient access.
  • PP Guard rails with build in steel frame provides protection from falling.
  • High quality sturdy PF (synthetic polymers) base mattress platform (Back and seat section), which is easily disinfected.
  • Removable Aluminium foot section which is easy to install,dissassemble and height adjustable.
  • With V shaped incision mattress section, Steel foam covered rotatable labour grips, Fixed rotatable leg support.
  • PF Foot pedal with built-in steel frame are flexible and adjusted to any position manually.
  • One Button Trendelburg position, Manual CPR with cushion to prevent instant drop.
  • Noiseless castors with Central braking system and battery backup.
  • Detachable head board / Provision for IV pole on both side of head postion.
  • SS basin / Night light / Bumper / Emergency stop button.

Specification parameters:

  • Overall size : L2320 x W990 x H485mm (± 10mm)
  • Mattress platform : L2000 x W860mm (± 10mm)
  • Lowest position (without mattress) : 485 (± 10mm)
  • Highest position (without mattress) : 860 (± 10mm)
  • back section angle : ≥ 63º
  • Maximum seat section angle : ≥ 15º
  • Maximum loading capacity : 227 kg

HF1927 : Electric Obstetric Bed - Multi Function

Standard Features:

  • This table is designed for women's obstetric and gynaecological operation, Easy operation, safe and reliable, economical and quick.
  • Operating positions - up / down, adjustable back rest & reverse trendelenburg position.
  • It adopts linear bearing to control the telescopic working table.
  • Size: 2000/1450 × 900/660 × 620/920 mm.
  • All motion controlled with T-Motion Power Device (Actuator) & Battery backup.
  • Adjustable leg support and sliding grip holder.
  • Main framework made of Expoxy Coated steel.
  • High quality beautiful ABS engineering plastic head panel.
  • Two easy lifting guardrails (1 on each side), which are safe and reliable, and can be fixed upward and downward.
  • 125mm dia noiseless castors with simultaneous braking system which locks / unlocks 2 castors with single pedal press.
  • Equipped with 8cm thick high quality foam mattress.

HF1925 : Obstetric Bed - Multi Function

Standard Features:

  • This table is designed for women's obstetric and gynaecological operation, Easy operation, safe and reliable, economical and quick.
  • Operating positions - up / down, forward and backward tilt are controlled by smooth hand wheel. Comfortable for both doctor and Patient.
  • Length and width for tabletop: 1800 x 600 mm.
  • Height adjustment range: 650 - 895mm.
  • Dimension of sections: backrest: 600 X 800 mm, Seat section: 600 x 400 mm, Leg section: 540 x 500 mm.
  • Max. degree for backrest adjustment: more than 60 degree upwards, more than 10 degree downwards.
  • Max. degree for tabletop forward and backward tilting: more than 8 degree(forward), more than 20 degree(backward).

HF1911 : Delivery Table / Delivery Couch

Standard Features:

  • Delivery Table / Bed, made in 3 sections.
  • Size: 1680 × 620 × 800 mm.
  • With adjustable Back rest & leg rest to varying positions.
  • Framework made of Mild Steel Epoxy coated finish.
  • Supplied with S.S. bowl and two leg holders.
  • Mounted on protective stumps.
  • Freight saving knock-down construction.

HF1915 : Delivery Table / Delivery Couch Stainless Steel

Standard Features:

  • Delivery Table / Bed, made in 3 sections.
  • Size: 1680 × 600 × 800 mm.
  • With adjustable Back rest & leg rest to varying positions.
  • Framework made of Stainless Steel.
  • Supplied with S.S. bowl and two leg holders.
  • Mounted on protective stumps.
  • Freight saving knock-down construction.

HF1920 : Delivery Bed, with Removable Legs Section On castor

Standard Features:

  • Delivery Table / Bed, made in 3 sections. Body Section with legs mounted on rubber tips, legs section on swivel castor with brakes.
  • Size: 1680 × 750 × 800 mm.
  • With adjustable back rest to varying positions.
  • Framework made of Mild Steel Epoxy coated finish.
  • Supplied with S.S. bowl and two leg holders.
  • Mounted on protective stumps.
  • Freight saving knock-down construction.
Item Code Type
HF1922 Same as HF1920, but stainless steel framework.

HF1927I : Electric Obstetric Bed

Standard Features:

  • Operating positions - Back rest, Trendelenburg / Reverse Trendelenburg, High-low, position maneuverable by remote.
  • Back rest: 0-75º
  • Trendelenburg: 0-12 º
  • Reverse Trendelenburg: 0-12º
  • Height Adjustment: 600 mm — 800 mm
  • Detachable polymer molded head and foot bows provide a soothing look.
  • Two easy lifting polymer side rails.
  • Central locking castors of Dia 125mm.
  • The complete metal components are Pretreated and Epoxy Powder Coated.
  • Provided with High Density three section mattress.
  • Corner PU buffers absorb impact and reduce damage in handling.
  • IV Stand with provision for fixing it at all four locations.
  • Frame size (Approx.): L 2130mm X W 1050mm (when fully extended)
  • Accessories : one collection tray, one set of lithotomy rod and crutches, one heavy duty IV pole, one set of hand grip.
  • Dust Protective Base Cover

HF068A : Delivery Table Telescopic (Fixed Height)

Standard Features:

  • Three sections top made of Stainless Steel
  • Leg section can slide completely under the main section.
  • Base frame made up of CRCA tubes.
  • Trendlenburg position adjustable by pneumatic pump.
  • Back rest adjustable on ratchet.
  • Height adjustable pair of knee crutches with straps
  • Supplied with mattress.
  • Pre treated and epoxy powder coated mild steel structure.
  • Size : L 1830 xW680 x H 760 mm.

HF071A : Delivery Table Telescopic (Adjustable Height)

Standard Features:

  • Frame made of Pre treated and epoxy powder coated mild steel.
  • Three sectional top made of Stainless Steel fixed on trolley base mounted on 125 mm castors.
  • Leg section can slide completely under the main section.
  • Tendelenburg position can be adjusted by using pneumatic pump.
  • Supplied with waste collecting stainless steel bowl and one Stainless Steel IV Rod.
  • Back rest adjustable on ratchet.
  • Hydraulic Height adjustable by foot paddle from side.
  • Hand grips.
  • Height adjustable knee crutches with straps,
  • Size : L 1830 x W 680 x H 600-760 mm.
Item Code Type
HF072A Specifications same as HF071A but, with Stainless Steel FrameWork and Stainless Steel Top

HF001 : Labour & Delivery Bed (With Accessories)

Standard Features:

  • Made in 2 sections, body section with legs mounted on rubber tips, legs section on swivel castors with brakes. Leg section can be completely recessed under the body section.
  • Size : Body section: L 1000 x W 800 x H 750mm. Leg section: L 900 x W 800 x H 750mm.
  • Supports for leg holders with solid mechanism to fix leg holders at required height and width.
  • Mattress-pad 2 sections.
  • Supplied with 2 legs holders with canvas straps OR 2 knee crutches (as desired) adjustable in height and width.
  • Epoxy coated tubular steel frame.
  • Mattress-pad density : 21-25 kg/m3.
  • Carrying capacity: 150 - 180 kg.
  • Mattress-pad: Approx. H 60mm.
  • Supplied with S.S. bowl.
  • Knockdown construction.

HF015 : Gynecology Table - DISMANTLED(With Accessories)

Standard Features:

  • Made in 3 sections, adjustable back rest and leg section with lever mechanism to varying positions, capable of tilting for obstetric and gynecological use. Legs mounted on rubber tips.
  • Size : Table 1800L x 600W x 800H mm. Tubes : 30 x 1.5 mm.
  • Supports for leg holders with solid mechanism to fix leg holders at required height and width.
  • Support ring at proximity of seat section to support round basin-bowl.
  • Supplied with 2 leg holders with canvas straps adjustable in height and width.
  • Epoxy coated tubular steel frame.
  • Tubes : 30 x 1.5mm.
  • Mattress-pad : density : 21 - 25 kg/m³.
  • Carrying capacity : 150-180 kg.
  • Mattress-pad : H 30 mm.
  • Knockdown construction.
  • Supplied with 4 liter S.S. Bowl.
  • Note : Available with knee crutches on request.

HF003 : Labour & Delivery Bed (With Accessories)

Standard Features:

  • Made in 2 sections, body section with legs mounted on rubber tips, legs section on swivel castors with brakes.
  • Size : Body section: 1000L x 800W x 750H mm., Leg section: 900L x 800W x 750H mm.
  • Supports for leg holders with solid mechanism to fix leg holders at required height and width.
  • Supplied with 2 legs holders with canvas straps OR 2 knee crutches (as desired) adjustable in height and width.
  • Epoxy coated tubular steel frame.
  • Carrying capacity: 150 - 180 kg.
  • Supplied with S.S. bowl.
  • Knockdown construction.

HF811 : Gynae Examination Table SS

Specifications/Details :

  • Complete Stainless Steel 304 Construction
  • Backrest movement on ratchet
  • Trendelenburg position through hydraulic pump
  • Sliding foot rest
  • Three section top with mattress and Knee Crutches
  • U Cut in center part with SS bowl
