Technical Specifications:

  • Illumination : 160000 Lux
  • Color temperature : 4300±500K
  • Color indication index (Ra) : 95
  • Power of LED : N128x1W
  • Spot diameter d50 : 130mm-350mm
  • Illumination depth : 140cm
  • Illumination-adjustment range : 10%~100%
  • Ultraviolet irradiance with wavelength under 400nm : 0.002W/m²
  • Focusing control : Manual
  • Perfect for endoscopy surgery
  • Power supply : 220V, 50Hz /110V, 60Hz
  • LED average service life : 60000hrs
  • Lowest height of installation : 2.8m
  •   Available in floor and wall configurations

      Technical specifications


  • Spot center illumination : 120000 Lux
  • Color temperature : 4300±500K
  • Color indication index (Ra) : 95
  • Power of LED : N64x1W
  • Spot diameter d50 : 130mm-350mm
  • Illumination depth : 120cm
  • Illumination-adjustment range : 10%~100%
  • Ultraviolet irradiance with
  • wavelength under 400nm : 0.002W/m²
  • Focusing control : manual
  • Power supply : 220V, 50Hz /110V, 60Hz
  • LED average service life : 60000hrs
  • Lowest height of installation : 2.8m
  •   Available in floor and wall configurations

      Technical specifications


  • Spot center illumination : 120000 Lux
  • Color temperature : 4300±500K
  • Color indication index (Ra) : 95
  • Power of LED : N8x1W
  • Spot diameter d50 : 130mm-350mm
  • Illumination depth : 120cm
  • Illumination-adjustment range : 10%~100%
  • Ultraviolet irradiance with
  • wavelength under 400nm : 0.002W/m²
  • Focusing control : Manual
  • Power supply : 220V, 50Hz /110V, 60Hz
  • LED average service life : 60000hrs
  • Lowest height of installation : 2.8m
  •   Available in floor and wall configurations

      Technical specifications


  • Illumination : 160,000 lux
  • Color temperature : 4300±500K
  • Color indication index (Ra) : 95
  • Power of LED : N16x1W
  • Spot diameter : 130mm-350mm
  • Illumination depth : 140cm
  • Illumination-adjustment range : 10%~100%
  • Ultraviolet irradiance with
  • wavelength under 400nm : 0.002W/m²
  • Focusing control : Manual
  • Power supply : 220V, 50Hz /110V, 60Hz
  • LED average service life : 60000hrs
  • Lowest height of installation : 2.8m
  •   Available in floor and wall configurations

      Technical specifications


  • Spot center illumination : 160000/120000 lux
  • Color temperature : 4300±500K
  • Color indication index (Ra) : 95
  • Power of LED : N16x1W/N8x1W
  • Spot diameter : 130mm-350mm
  • Illumination depth : 140cm/120cm
  • Illumination-adjustment range : 10%~100%
  • Ultraviolet irradiance with
  • wavelength under 400nm : 0.002W/m²
  • Focusing control : Manual
  • Power supply : 220V, 50Hz /110V, 60Hz
  • LED average service life : 60000hrs
  • Lowest height of installation : 2.8m

      Technical specifications


  • Spot center illumination : 160000/120000 lux
  • Color temperature : 4300±500K
  • Color indication index (Ra) : 95
  • Power of LED : N128x1W/N64x1W
  • Spot diameter : 130mm-350mm
  • Illumination depth : 140cm/120cm
  • Illumination-adjustment range : 10%~100%
  • Ultraviolet irradiance with
  • wavelength under 400nm : 0.002W/m²
  • Focusing control : Manual
  • Power supply : 220V, 50Hz /110V, 60Hz
  • LED average service life : 60000hrs
  • Lowest height of installation : 2.8m
  • Diameter of lamp head : Main lamp, -600mm
  • Illumination : Main lamp, 70000 lx ~ 160000 lx, Subsidiary Color temperature : 3000k ~ 6000k
  • Color rendering index : 92 ~ 100
  • Diameter of Spot: D10 Main lamp 120mm, Subsidiary : D50 Main lamp 70mm, Subsidiary
  • Depth of illumination : = 600mm
  • Adjustment of Height : 800mm
  • Brightness control : 9 steps
  • Total radiation illumination : = 500W/M2
  • Power supply : A.C100 ~ 220V 50 HZ
  • Power consumption : 50VA
  • Power of bulb : 3 WLED
  • Number of LED Bulbs : Main lamp, 21
  • Illumination Intensity : 80000-150000 Lux
  • Color Temperature : 3500-5000 K
  • Spot Diameter : 100-250 mm
  • Illumination Depth : 600 mm
  • Height Adjustment : 800 mm
  • Lamphead Diameter : 700 mm
  • Brightness Control : 9-level dimmable
  • Temperature Rise of Field : ≤ 2 (°C)
  • Power Supply : 220V / 50Hz
  • Power Input : 200 VA
  • Specification of Bulb : 150 Watt / 24 Volt
  • Minimum Height for Installation : 2700 mm
  • Automatic Switchover Between the Key and Backup Bulbs : Yes
  • Illumination Intensity : 80000-150000 Lux
  • Color Temperature : 3500-5000 K
  • Spot Diameter : 100-250mm
  • Illumination Depth : 600mm
  • Height Adjustment : 800mm
  • Lamphead Diameter : 600mm
  • Brightness Control : 9-level dimmable
  • Temperature Rise of Field : ≤ 2 (°C)
  • Power Supply : 220V /50Hz
  • Power Input : 200 VA
  • Specification of Bulb : 150Watt / 24 Volt
  • Minimum Height for Installation : 2660mm
  • Automatic Switchover Between the Key and Backup Bulbs : Yes
  • Illumination Intensity : 30000-50000 Lux
  • Color Temperature : 3500-5000 K
  • Spot Diameter : 100-200mm
  • Height Adjustment : 260mm
  • Lamphead Diameter : 500mm
  • Power Supply : 220V / 50Hz
  • Power Input : 150 VA
  • Illumination Intensity : 100000~160000 Lux
  • Color Temperature : 3500-5000 K
  • Spot Diameter : 120-250mm
  • Height Adjustment : 700mm
  • Lamphead Diameter : 800mm
  • Brightness Control : 9-level dimmable
  • Temperature Rise of Field : ≤2 (°C)
  • Power Supply : 220V / 50Hz
  • Power Input : 400 VA
  • Specification of Bulb : 50Watt / 24 Volt
  • Minimum Height for Installation : 2750mm
  • Illumination Intensity : 42000-70000 Lux
  • Color Temperature : 3500-5000 K
  • Spot Diameter : 100-200mm
  • Height Adjustment : 440mm
  • Lamphead Diameter : 700mm
  • Power Supply : 220V / 50Hz
  • Power Input : 210 VA
  • Illumination Intensity : 54000-90000 Lux
  • Color Temperature : 3500-5000 K
  • Spot Diameter : 100-200mm
  • Height Adjustment : 440mm
  • Lamphead Diameter : 900mm
  • Power Supply : 220V / 50Hz
  • Power Input : 270 VA
  • Illumination Intensity : 72000-120000 Lux
  • Color Temperature : 3500-5000 K
  • Spot Diameter : 100-200mm
  • Height Adjustment : 440mm
  • Lamphead Diameter : 900mm
  • Power Supply : 220V / 50Hz
  • Power Input : 360 VA
  • Illumination Intensity : 30000-60000 Lux
  • Color Temperature : 3000-4500 K
  • Spot Diameter : 80-150mm
  • Height Adjustment : 700mm
  • Lamphead Diameter : 195mm
  • Power Supply : 200V / 50Hz
  • Power Input : 75 VA
  • Specification of Halogen Bulb : 50Watt / 24 Volt
  • Brightness Control : Digital Control
