NEEDLE : Siliconised, bevelled, back cut ground stainless steel needle for smooth and painless venipuncture. Made of Stainless Steel AISI304, diameter and length according to ISO standard.

NEEDLE HUB: All I.V.Cannulae have specially designed needle hub to prevent any de-stabilisation and bending of the needle during venipuncture. Specially curved thumb guard for proper grip during insertion.

NEEDLE COVER: Protects the needle and catheter from contamination. Prevents accidental damage to the needle and catheter.

CATHETER: PTFE (Poly Tetra Fluoro Ethylene) / FEP catheter is dual tapered, bevelled tip & siliconized which offers high resistance to kinking. Minimum resistance during insertion due to its lowest coefficient of friction & improved tip design. High chemical resistance and excellent bio compatibility. Thin walled catheter allows maximum flow rate for a specific gauge of Cannula. Optimum trim distance. Choice between stripped radiopaque and transparent catheter.

FLASH BACK CHAMBER: Flash back chamber allows monitoring of instantaneous flash of blood after venipuncture confirming correct catheter placement. Specially designed to prevent any spillage of blood.

WINGS (DS101 & DS105): Angled wings offer easy fixation and prevent slipping & rolling of cannula over the patients body.

INJECTION PORT (DS101 ONLY): Provided with injection site. Which has one way retreating valve (silicon tube) to facilitate extra medication and to prevent back flow. The Injection valve is provided with specially designed cap incorporating a recessed plug with a protective skirt to effectively prevent contamination when the valve is not in use. It offers safe and convenient method of atraumatic administration of medicines. Colour coded to identify the gauge of the needle.

The product is sterile and individually packed in rigid blister sealed with peel-open type medical grade paper. (Tyvek packing available upon request). Disposable, Sterile, non-toxic and Non-Pyrogenic. Each I.V. Cannula is provided with a threaded stopper.
Item Code Size
DS101-14 14G
DS101-16 16G
DS101-17 17G
DS101-18 18G
DS101-20 20G
DS101-22 22G
DS101-24 24G
DS101-26 26G

I.V. CANNULAE
Size Colour I.D.
in mm.
O.D.
in mm.
Length
in mm.
Water Flow
in ml./min.
14G Orange 1.7 2.1 45 270
16G Grey 1.3 1.7 45 180
17G White 1.1 1.5 45 125
18G Green 0.9 1.3 45 80
20G Pink 0.8 1.1 32 54
22G Blue. 0.6 0.9 25 33
24G Yellow. 0.5 0.7 19 20
26G Voilet 0.4 0.6 19 19
PRODUCT FEATURES:

100% Safety: Our I.V. Cannulae can be used safely without the risk of Thrombophlebitis. It is made of Virgin P.T.F.E. (Ply Tetra Fluro Ethylene) Catheter, one of the most bio-compatible materials known to man. Virgin P.T.F.E. Catheter: As P.T.F.E. has the lowest coefficient of friction, our I.V. Cannulae reduces the chances of sticking to vascular walls. The P.T.F.E. clear catheter, designed and made double tapered with a formed tip & siliconisation, offers lower resistance during insertion, resulting in less trauma to the patient and it avoids peel back effect. The thin walled catheter has a large diameter, leading to 10% faster flow rate.

Improved Siliconised Needle Point: Precisely honed point enables smoother penetration for rapid closure after needle withdrawal and this also reduces fluid seepage and Postdural Puncture Headache (PDPH.). Minimises the chance of inadvertent nerve damage.

Soft And Smooth Needle Cover: Protects the precisely honed needle point during handling.

Needle Hub: The extra thin walled needle has a hub with a large crystal clear flash back chamber indicates perfect and successful venipuncture with blood entry. The holding area of the needle hub is specially designed according to thumb impression, resulting in easy insertion and firm holding pressure of thumb on the smooth surface of the hub. Fully covered needle hub stabilises the needle inside the catheter to make insertion easier and safer.

Injection Port With A Snap Fit Protection Cap: This allows injection of medicine during infusion. Since the non-return valve can be opened only under pressure, the valve does not open accidentally, thereby preventing contamination.

Flexible Grooved Wings: The wings provide an angle between the plane of the wings and catheter, resulting in easy and comfortable adjustment after catheter insertion into the vein. The grooved wings helps ease skin fixation and prominent gripping.

Unique Porous Filter: The needle end is covered with a unique porous filter (fitted in needle hub) resulting in a higher flow rate and quick easy confirmation of correct vascular access. Avoids blood spillage and prevents formation of air bubbles.

Threaded Stopper With Luer Lock: This is the stopper used to stop the blood spillage after infusion is stopped. The threads inside the stopper tightens the stopper on main body and the luer lock confirms the stoppage of blood spillage.
Item Code Size
DS105-16 16G
DS105-18 18G
DS105-20 20G
DS105-22 22G
DS105-24 24G
DS105-26 26G
PRODUCT FEATURES:

100% Safety: Our I.V. Cannulae can be used safely without the risk of Thrombophlebitis. It is made of Virgin P.T.F.E. (Ply Tetra Fluro Ethylene) Catheter, one of the most bio-compatible materials known to man. Virgin P.T.F.E. Catheter: As P.T.F.E. has the lowest coefficient of friction, our I.V. Cannulae reduces the chances of sticking to vascular walls. The P.T.F.E. clear catheter, designed and made double tapered with a formed tip & siliconisation, offers lower resistance during insertion, resulting in less trauma to the patient and it avoids peel back effect. The thin walled catheter has a large diameter, leading to 10% faster flow rate.

Improved Siliconised Needle Point: Precisely honed point enables smoother penetration for rapid closure after needle withdrawal and this also reduces fluid seepage and Postdural Puncture Headache (PDPH.). Minimises the chance of inadvertent nerve damage.

Soft And Smooth Needle Cover: Protects the precisely honed needle point during handling.

Needle Hub: The extra thin walled needle has a hub with a large crystal clear flash back chamber indicates perfect and successful venipuncture with blood entry. The holding area of the needle hub is specially designed according to thumb impression, resulting in easy insertion and firm holding pressure of thumb on the smooth surface of the hub. Fully covered needle hub stabilises the needle inside the catheter to make insertion easier and safer.

Injection Port With A Snap Fit Protection Cap: This allows injection of medicine during infusion. Since the non-return valve can be opened only under pressure, the valve does not open accidentally, thereby preventing contamination.

Flexible Grooved Wings: The wings provide an angle between the plane of the wings and catheter, resulting in easy and comfortable adjustment after catheter insertion into the vein. The grooved wings helps ease skin fixation and prominent gripping.

Unique Porous Filter: The needle end is covered with a unique porous filter (fitted in needle hub) resulting in a higher flow rate and quick easy confirmation of correct vascular access. Avoids blood spillage and prevents formation of air bubbles.

Threaded Stopper With Luer Lock: This is the stopper used to stop the blood spillage after infusion is stopped. The threads inside the stopper tightens the stopper on main body and the luer lock confirms the stoppage of blood spillage.
Item Code Size
DS110-16 16G
DS110-18 18G
DS110-20 20G
DS110-22 22G
DS110-24 24G
DS110-26 26G
  • Gravity type flow regulator.
  • Colored flow controller part.
  • Scale range from 2 ml to 350 ml.
  • Constant flow rate.
  • Universal male and female luer connections.
  • Biocompatible hose.
  • Y-port injection.
  • Total length 45 cm

Minimum order quantity 1x20’ container assorted

Size 2-part Luer Slip 3-part Luer Slip 3-part Luer Lock AD Syringe with Needle, 3-Part Safety Syringe with Sliding Sheath with Needle
0.05 ml - - - DS535-0.05 -
0.1 ml - - - DS535-0.1 -
0.5 ml - - - DS535-0.5 -
1 ml - DS505-1 - DS535-1 DS540-1
2 ml DS500-2 DS505-2 DS510-2 DS535-2 DS540-2
3 ml DS500-3 DS505-3 DS510-3 DS535-3 DS540-3
5 ml DS500-5 DS505-5 DS510-5 DS535-5 DS540-5
10 ml DS500-10 DS505-10 DS510-10 DS535-10 DS540-10
20 ml DS500-20 DS505-20 DS510-20 - -
30 ml - DS505-30 DS510-30 - -
50 ml - DS505-50 DS510-50 - -
Item Code Size
DS40-16 16G
DS40-18 18G
DS40-19 19G
DS40-20 20G
DS40-21 21G
DS40-22 22G
DS40-23 23G
DS40-24 24G
DS40-25 25G
DS40-26 26G
DS40-27 27G
  • Scalp Vein Set is used for rapid venous access and for the greater patient comfort during infusion.
  • Manufactured from non toxic, medical grade PVC compound.
  • Thin wall, short bevel Needle facilitates non traumatic penetration.
  • Wings are for better handling and attachment to the skin.
  • Wings are colour coded for instant size identification.
  • Proximal end of the set is provided Female luer fitting for easy connection with the infusion set.



  • PACKING:
  • Sterile, individually packed in peelable pouch pack.
  • Box of 100; Master Carton of 4000.
Item Code Size
DS195-18 NG 18
DS195-19 NG 19
DS195-20 NG 20
DS195-21 NG 21
DS195-22 NG 22
DS195-23 NG 23
DS195-24 NG 24
DS195-25 NG 25
CENTRAL VENOUS CATHETERS Syringe
5cc LL
Introducer
Syringe

Syringe 5cc LL Y needle in place of reg needle
Catheter Type Lumen Dilator Guide Wire Needle Code Code Code
Size & Length (Ga) (Fr) (dia "xcms)
Single lumen
14 Ga x20cm 14 8 Fr 0.035x45 cm 18 Ga, 7cm DS1000-14 DS1002-14 DS1006-14
16 Ga x20cm 16 6 Fr 0.035x45 cm 18 Ga, 7cm DS1000-16 DS1002-16 DS1006-16
18 Ga x20cm 18 5 Fr 0.025x45 cm 18 Ga, 7cm DS1000-18 DS1002-18 DS1006-18
20 Ga x13cm 20 4 Fr 0.025x45 cm 20 Ga, 7cm DS1000-20 DS1002-20 DS1006-20
22 Ga x10cm 22 4 Fr 0.021x45 cm 20 Ga, 7cm DS1000-22 DS1002-22 DS1006-22
22 Ga x 4cm 22 4 Fr 0.021x45 cm 21 Ga,3.8cm DS1000-22.1 DS1002-22.1 DS1006-22.1
24 Ga x13cm 24 4 Fr 0.081x45 cm 21 Ga,3.8cm DS1000-24 DS1002-24 DS1006-24
Double lumen
4 Fr x 8cm 20, 22 5 Fr 0.018x 45 cm 21 Ga, 3.8 cm DS1001-4 DS1003-4 DS1004-4
5 Fr x 8cm 18, 20 6 Fr 0.021x 45 cm 20 Ga, 3.8 cm DS1001-5 DS1003-5 DS1004-5
7 Fr x 16cm 14, 18 8 Fr 0.035x 45 cm 18 Ga, 7 cm DS1001-7 DS1003-7 DS1004-7
Triple lumen
4.5 Fr x 6cm 20, 22, 22 6 Fr 0.018x 45 cm 21 Ga, 3.8cm DS1005-4.5 DS1006-4.5 DS1007-4.5
5.5 Fr x 6/8cm 20, 22, 22 6 Fr 0.018x 45 cm 21 Ga, 3.8cm DS1005-5.5 DS1006-5.5 DS1007-5.5
7 Fr x 16cm 16, 18, 18 8 Fr 0.035x 45 cm 18 Ga, 7cm DS1005-7 DS1006-7 DS1007-7
8.5 Fr x16cm 14, 16, 16 9 Fr 0.035x 45 cm 18 Ga, 7cm DS1005-8.5 DS1006-8.5 DS1007-8.5

Four lumen

8.5 Fr x16cm 14, 16,18,18 9 Fr 0.035x 45 cm 18 Ga 7cm DS1008-8.5 DS1009-8.5 DS1010-8.5
