Plasma Sterilizer H2o2, Low Temperature, 100 litres

XGQ-100 : Plasma Sterilizer H2o2, Low Temperature, 100 litres

In Stock

NET brand Plasma Sterilizer H2o2, Low Temperature, 100 litres is a high quality product and trusted all across the globe. Plasma Sterilizer H2o2, Low Temperature, 100 litres is being manufactured and supplied by the company reputed because of excellent product quality, friendly service and professional approach. Scroll down to see specifications and reviews.

Ask Price

Technical Data Sheets

Usage

Sterilizer takes H2O2 as sterilizing agent and form plasmatic state of H2O2 by electromagnetic field under low temperature. It combines both gaseous and plasmatic H2O2 to make sterilization for the items in chamber and decomposes the residual H2O2 after sterilization.

It is widely used in CSSD or other medical institute for the sterilization of electric wire and cable, optical glasses and glass lens, power equipment and batteries, endoscopes, catheter, non-metallic and other wet or heat sensitive instruments.

Technical data
1	Chamber Dimension / Volume	750(D) × 450(W) × 400(H) mm / 135 L
2	Chamber Structure & Material	Rectangular, Aluminum alloy
3	Overall Dimension	990(D) × 760(W) × 1600(H) mm
4	Door Type	Single/Double door, automatic vertical sliding, touch screen operation
5	Loading Method	Shelf loading, double layers
6	Installation Mode	Floor mounted
7	Programs	Standard cycle, Express cycle, Leak test
8	Sterilization Cycle Time	≤50 min (Standard), ≤26 min (Express)
9	Sterilization Temperature	50°C ±5°C
10	Sterilization Medium	H₂O₂ solution, 60% concentration
11	H₂O₂ Solutions injection mode	Cassette type, 12 capsules on each cartridge 2.2mI H2O2 per capsule.
12	H₂O₂ Consumption	2 capsules per full cycle, 1 capsules per express cycle
13	Weight	400 kg
14	Power Supply	Driving power: AC 380 V ± 10% 3 phases 50/60 Hz, 3.8Kw (Standard)
15	Display	5.7” true color Touch screen display and operation
16	Data printer	Built-in thermal printer
17	Loading method	Loading shelves
18	Biological indicator	56ºC, 48hº
