Autoclaves Pressure Steam Sterilizers


Autoclaves/ Pressure Steam Sterilizers, Aluminum - Seamless (Super Deluxe Series)

The Super Deluxe Series Autoclaves are sturdily constructed in rustproof, heavy gauge aluminum for use in rugged condition. Its a unique vessel that generates steam under pressure and temperature between 120°C to 125°C. On reaching the right temperature the instruments are subject to a saturated steam environment for a pre-specified time which results in safe and guaranteed sterilization. Available in various models and sizes from 6 liters capacity to 39 liters capacity to suit different application. These can be used on electricity as well as on any external heat source such as kerosene stove, gas burner, wood & charcoal.

Features and Benefits:

  • All aluminum deep drawn seamless construction.
  • Light, compact, portable, easy to use top loading autoclaves.
  • Fast 20 min. sterilizing cycle at 121° c.
  • Equipped with two stages over pressure protection system incorporating a calibrated continuous bleeding pressure stopcock and pressure release weight valve.
  • Extended life gasket & heating element.
  • Equipped with heat resistant handles and steam release / control valve.
  • For assurance of quality each autoclave is tested to the parameter of successful sterilization.
  • Optional TST indicator stickers provide independent verification that the correct combination of temperature, steam & time has been achieved for successful sterilization.
  • Pressure Gauge: Colour coded pressure gauge showing internal chamber conditions during the cycle. Sterilization zone in green colour is shown from 15 psi to 20 psi (OR 1.034 bar to 1.378 bar) which is equivalent To temperature of 121°C to 127°C. Dial size : 2.5". Dial show measurement in 2 units (i) kg/cm2 (ii) lb/inch2. Full scale dial of pressure gauge is 0-30 lb/inch2 or 0-2 kg/cm2 . Caution zone in red colour.
  • Inclusive of - inner & outer stand.
  • Optional (to be ordered separately) - Inside container / baskets / dressing drums, timer and spares.
Item Code Capacity (Lt.)
including lid
Power Size (dia. x height) Type
AU410 11 Electric 220 x 300mm = 9” x 11” Mirror/Polished Finish
AU420 15 Electric 300 x 225mm = 12” x 9” Mirror/Polished Finish
AU430 21 Electric 300 x 300mm = 12” x 12” Mirror/Polished Finish
AU440 24 Electric 300 x 350mm = 12” x 14” Mirror/Polished Finish
AU450 28 Electric 300 x 400mm = 12” x 16” Mirror/Polished Finish
AU460 38 Electric 350 x 400mm = 14” x 16” Mirror/Polished Finish
AU470 39 Electric 300 x 550mm = 12” x 22” Mirror/Polished Finish
Item Code Capacity (Lt.)
including lid
Power Size (dia. x height) Type
AU411 11 Non Electric 220 x 300mm = 9” x 11” Mirror/ Polished Finish
AU421 15 Non-Electric 300 x 225mm = 12” x 9” Mirror/ Polished Finish
AU431 21 Non-Electric 300 x 300mm = 12” x 12” Mirror/ Polished Finish
AU441 24 Non-Electric 300 x 350mm = 12” x 14” Mirror/ Polished Finish
AU451 28 Non-Electric 300 x 400mm = 12” x 16” Mirror/ Polished Finish
AU461 38 Non-Electric 350 x 400mm = 14” x 16” Mirror/ Polished Finish
AU471 39 Non-Electric 300 x 550mm = 12” x 22” Mirror/ Polished Finish
Item Code Capacity (Lt.)
including lid
Power Size (dia. x height) Type
AU412 11 Electric 220 x 300mm = 9” x 11” Epoxy Coated
AU422 15 Electric 300 x 225mm = 12” x 9” Epoxy Coated
AU432 21 Electric 300 x 300mm = 12” x 12” Epoxy Coated
AU442 24 Electric 300 x 350mm = 12” x 14” Epoxy Coated
AU452 28 Electric 300 x 400mm = 12” x 16” Epoxy Coated
AU462 38 Electric 350 x 400mm = 14” x 16” Epoxy Coated
AU472 39 Electric 300 x 550mm = 12” x 22” Epoxy Coated

*We supply 220V, 50Hz, single phase, electric equipment, unless otherwise specified in your order.

Note: For Autoclave with timer please suffix 'T' to our Autoclaves Codes.


AU402 : Rack Steam Sterilizer, Single Rack

Steam sterilizer, pressure type, single rack, used to sterilize reusable: syringes and needles. Aluminium vessel with high pressure seal suitable for carrying out sterilisation using superheated steam. Steam sterilizer designed to operate on external heat source (non-electric) at +121°C over a 20 minute period.

  • Components: Aluminium vessel with heat resistant handles. Aluminium cover with heat resistant handles , rubber sealing gasket, pressure valve & safety plug. 1 aluminium rack with 1 lid, for 36 syringes ( 4 syringes 5ml, 16 syringes 2 ml, 16 syringes 1 ml) and 40 needles. Sterilization capacity: 5.5 litres.
  • Supplied with: 1 x sterilization indicator sticker (pack of 100), 3 x spare sealing gaskets, 1 x plastic bowl for washing syringes, 1 x carrying bag, 1 x user manual in English.

AU414 : Rack Steam Sterilizer, Double Rack

Steam sterilizer, pressure type, double rack, used to sterilize reusable: syringes and needles. Aluminium vessel with high pressure seal suitable for carrying out sterilization using superheated steam. Steam sterilizer designed to operate on external heat source (non-electric) at +121°C over a 20 minute period.

  • Components: Aluminium vessel with handles. Aluminium cover with handles and rubber sealing gasket. Pressure valve. Safety plug. 2 aluminium racks with 2 lid, for 64 syringes (44 syringes 2 ml, 16 syringes 1 ml, 4 syringes 5 ml) and 80 needles per rack. Sterilization capacity: 9 litres.
  • Supplied with: 1 x sterilization indicator sticker (pack of 100), 3 x spare sealing gaskets, 1 x plastic bowl for washing syringes, 1 x carrying bag, 1 x user manual in English.

Accessories for Rack Sterilizer
Item Code Title
AU610 Aluminium single rack with 1 lid, 36 Syringes (4 syringes 5ml, 16 syringes 2ml, 16 syringes 1ml) and 40 needles.
AU611 Aluminium double racks with 2 lid, for 64 Syringes (44 syringes 2ml, 16 syringes 1ml, 4 syringes 5ml) and 80 needles per rack
AU612 Heat resistant handle with screws (pair pack).
AU613 Sterilisation indicator sticker (pack of 100).
AU615 Sealing gaskets for rack sterilizer.

Autoclaves Pressure Steam Sterilizers (Aluminum) - Economy Mirror / Polished Finish

Construction: These autoclaves are made of 10 gauge aluminum. The drum is deep drawn & the ring on top is riveted. The lid is made by casting. Locking of lid by 6 nuts with rubber gasket seal in between (not metal to metal seal). Two safety valves, pressure gauge, flexible metal rubbing to exhaust air. Includes outer stand, inner aluminum container, inner tripod stand.

Item Code Capacity(Lt.) Power Size Type
AU101 20 Lt. Electric 300 x 300mm = 12” x 12” Mirror Finish
AU102 20 Lt. Non Electric 300 x 300mm = 12” x 12” Mirror Finish
AU103 25 Lt. Electric 300 x 380mm = 12” x 15” Mirror Finish
AU104 25 Lt. Non Electric 300 x 380mm = 12” x 15” Mirror Finish
AU105 35 Lt. Electric 350 x 380mm = 14"x15" Mirror Finish
AU106 35 Lt. Non Electric 350 x 380mm = 14"x15" Mirror Finish

Autoclaves / Pressure Steam Sterilizers (Aluminum, Deluxe Series)

Construction: Superior quality & finish. All these autoclaves are made of 8 gauge aluminum. The drum is deep drawn. The lid is die casted. Locking of lid by 6 nuts with rubber gasket seal in between (no metal to metal seal). Two safety valves, pressure gauge, flexible metal tubing to exhaust air. Includes outer stand, inner tripod stand.

Features:
  • Equipped with two stages "over pressure" protection system incorporating a calibrated continuous bleeding Pressure stopcock and pressure release weight valve.
  • Pressure Gauge : Colour coded pressure gauge showing internal chamber conditions during the cycle. Sterilization zone in green colour is shown from 15 psi to 20 psi (or 1.034 bar to 1.378 bar) which is equivalent to temperature of 121°c to 127°c. Dial size : 2.5". Dial show measurement in 2 units (i) kg/cm2 (ii) lb/inch2 Full scale dial of pressure gauge is 0-30 lb/ inch2 or 0-2 kg/cm2. Caution zone in red colour.
  • Equipped with steam release /control valve and flexible metal exhaust tube. For assurance of quality each autoclave is tested to the parameter of successful sterilization.
  • All aluminum deep drawn seamless construction of base unit.
  • Heavy cast aluminum lid with six wing nut.
  • Easy to use top loading autoclaves.
  • Fast 20 min. sterilizing cycle at 121° C.
Item Code Capacity(Lt.) Power Size Type
AU201 21 Electric 300 x 300mm = 12” x 12” Mirror Finish
AU202 21 Non Electric 300 x 300mm = 12” x 12” Mirror Finish
AU205 37 Electric 350 x 380mm = 14"x15" Mirror Finish
AU206 37 Non Electric 350 x 380mm = 14"x15" Mirror Finish

*We supply 220V, 50Hz, single phase, electric equipment, unless otherwise specified in your order.


Autoclaves Pressure Steam Sterilizers (Stainless Steel) - Seamless

Construction: These portable vertical autoclaves are made out of thick high quality (14 gauge) stainless steel sheet, deep drawn to cylindrical shape, having no joints and welding. Seamless construction allows no bacteria residue and free from dirt accumulation. Fitted with pressure gauge, safety valve (weight type), seam/pressure release cock, lid and top handle. Lid is similar to pressure cooker with locking over rubber gasket. Portable vertical pressure type, easy to use top loading autoclaves. The steam pressure inside with autoclave can develop from 1.10 kgf / sq.cm (15 psi) to 1.25 kgf / sq.c (18 psi).

Item Code Capacity(Lt.) Power Size Type
AU001 30 Lt Electric 350 x 300mm = 14” x 12” Mirror Finish
AU002 30 Lt Non Electric 350 x 300mm = 14” x 12” Mirror Finish

*We supply 220V, 50Hz, single phase, electric equipment, unless otherwise specified in your order.


AU850 : Autoclave 10 Litre Electric
  • Stainless Steel 304 seamless construction.
  • Auto cut-off heating element and indication light.
  • With time adjustment facility.
  • Dimension : 235mm Dia x 235mm Ht. (with Lid).

Note: Height and capacity adjustable as per customers requirement.


AU855 : Autoclave 10 Litre Non-Electric
  • Stainless Steel 304 seamless construction.
  • With Outer Stand.
  • Dimension : 235mm Dia x 240mm Ht. (with Lid).

Note: Height and capacity adjustable as per customers requirement.


AU860 : Autoclave 11 Litre Electric

Standard Features:

  • Stainless Steel 304 seamless construction.
  • Dimension : 220mm Dia x 300mm.Ht. (with Lid).

Note: Height and capacity adjustable as per customers requirement.


AU865 : Autoclave 11 Litre Non Electric
  • Stainless Steel 304 seamless construction.
  • Dimension : 220mm Dia x 300mm Ht.

Note: Height and capacity adjustable as per customers requirement.


Containers & Baskets for Steam Sterilizers/ Autoclaves
Item Code Size Type
AU600 204mm dia. x 190mm ht. Aluminium basket with handle
AU601 260mm dia x 230mm ht. Aluminium basket with handle
AU602 260mm dia x 330mm ht. Aluminium basket with handle
AU603 300mm dia x 300mm ht. Aluminium basket with handle
AU604 250mm dia x 51mm ht. Aluminium container, low height
AU605 300mm dia x 51mm ht. Aluminium container, low height
AU640 200mm dia x 260mm ht. Stainless Steel Wire Basket
AU643 270mm dia x 290mm ht. Stainless Steel Wire Basket
AU647 330mm dia x 370mm ht. Stainless Steel Wire Basket 500ml,two sides are ribbed, Packed in poly bag
AU650 205mm dia x 165mm ht. Plastic Autoclavable Perforated Basket with handle 500ml,two sides are ribbed, Packed in poly bag

Note: We supply 220V, 50Hz, single phase, electric equipment; unless otherwise specified in your order.


Stainless Steel Wire Mesh Trays And Wire Baskets
  • These sterilizing Trays made in Stainless Steel 304, allow a systematic organization of instrument for sterilization. The comfortable handling provides safety and control through all fields of applications in sterilization. Storage and transportation are also perfectly organized with these trays.
  • Available in various sizes & designs to accommodate wide range of Surgical Instruments & Equipment.
Item Code Dimensions
AU801 500 X 250 X 30mm
AU803 500 X 250 X 50mm
AU805 500 X 250 X 70mm
AU807 500 X 250 X 100mm
AU809 400 X 200 X 30mm
AU811 400 X 200 X 50mm
AU813 400 X 200 X 70mm
AU815 400 X 200 X 100mm
AU817 250 X 250 X 30mm
AU819 250 X 250 X 50mm
AU821 250 X 250 X 70mm
AU823 250 X 250 X 100mm

Other Spares/ Accessories for Steam Sterilizers/Autoclaves
Item Code Dimensions
AU613 Sterilization indicator sticker (pack of 100).
AU620 Heat resistant handles for super deluxe series (specify size of autoclave) with screws (pair pack)
AU621 Immersion heater for autoclave, 2 kw.
AU622 Rubber gasket ( specify dia of autoclave).
AU623 Pressure gauge 0-30 psi, colour coded.
AU624 Excess pressure release valve.
AU625 Calibrated continuous bleeding stop cock.
AU626 Bakelite wing nut for economy Autoclave
AU627 Steam release knob.
AU628 Flexible metal exhaust tube with release knob.
AU629 Timer 0-60 minutes ( built-in in any electric autoclave).
AU630 Electric cord with plug and socket for autoclave.
MZ015 Timer 0-60 minutes, independent (see under miscellaneous product head).


AU653 : Light Weight Disinfection Tray System
  • This tray system is the nice sterilizing / disinfecting / soaking tray that is essential for sterilization of certain instruments & equipment which cannot be sterilized under steam & pressure in Autoclaves. These can be also used as a back up to your other sterilizing system.
  • The tray includes Outer Tray with lid & a Lift-out drain baskets with handles to facilitate lifting of instruments in and out of the soaking solution. Lid protect against spillage and minimize vapors.
  • Dimension: Outer tray measures 845mm L x 225mm W x 150mm H
  • Volume Capacity: 10 liters appx, [NON AUTOCLAVABLE]
