Fowler Beds

NET Fowler beds are ergonomically designed, four section perforated beds utilized for knee rest and backrest functions. The beds, operated using cranks or motors, utilize either simultaneous, central or individual braking system. These fowler beds are equipped with easy lifting or collapsible side rails to ensure patient safety. Stainless Steel or ABS are used for the head and foot panels.

You may select the most suitable model from our extensive range of Fowler beds and inform us your specific purchase requirement so that we can offer you CIF prices.

Watch Video

HF1151a - Fowler Bed Manual

Standard Features:

  • Fowler Bed with mechanically operated back rest and knee rest by super-smooth crank mechanism.
  • Size: L 2140mm × W 940mm × H 500mm.
  • Two easy lifting guardrails (1 on each side), which are safe and reliable, and can be fixed upward and downward.
  • Removable & interchangeable high quality beautiful ABS engineering plastic head panel and foot panel.
  • Epoxy coated mild steel frame work and 4 section perforated top.
  • 125mm dia noiseless castors with Central braking system.
  • Provision for I.V. Rod, with basket.

HF1153a - Fowler Bed Manual

Standard Features:

  • Fowler Bed with mechanically operated back rest and knee rest by super-smooth crank mechanism.
  • Size: L 2160mm × W 970mm × H 530mm.
  • Four easy lifting guardrails (2 on each side), which are safe and reliable, and can be fixed upward and downward.
  • Removable & interchangeable high quality beautiful ABS engineering plastic head panel and foot panel. Equipped with roller Bumper.
  • Epoxy coated mild steel frame work and 4 section perforated top.
  • 125mm dia noiseless castors with Central braking system.
  • Provision for I.V. Rod.

HF1162 - Fowler Bed, Manual, 2 Function

Standard Features:

  • Fowler Bed with mechanically operated back rest and knee rest by super-smooth crank mechanism.
  • Size: L 2140mm × W 940mm × H 500mm.
  • Removable & interchangeable high quality beautiful ABS engineering plastic head panel and foot panel.
  • Collapsible side railings. (Top bar Aluminium, Vertical bars SS, Bottom pipe epoxy)
  • Epoxy coated mild steel frame work and 4 section wire mesh platform.
  • 125mm dia noiseless castors with central braking.
  • Provision for I.V. Rod.

HF1166 - Fowler Bed, Manual, Two Function

Standard Features:

  • Fowler Bed with mechanically operated back rest and knee rest by super-smooth crank mechanism.
  • Size: L 2140 × W 940 × H 500mm.
  • Removable & interchangeable high quality beautiful flat tube head panel and foot panel.
  • Collapsible side railings. (Top bar Aluminium, Vertical bars SS, Bottom pipe epoxy)
  • Epoxy coated mild steel frame work and 4 section perforated top.
  • 125mm dia noiseless castors with Central braking system.
  • Provision for I.V. Rod on both sides of the bed.

HF1171 - Fowler Bed, Manual, Two Function

Standard Features:

  • Fowler Bed with mechanically operated back rest and knee rest by super-smooth crank mechanism.
  • Size: L 2190mm × W 980mm × H 500mm.
  • Removable & interchangeable high quality beautiful ABS engineering plastic head panel and foot panel.
  • Collapsible side railings. (Top bar Aluminium, Vertical bars SS, Bottom pipe epoxy)
  • Epoxy coated mild steel frame work and 4 section perforated top.
  • 125mm dia noiseless castors (all with individual brakes)
  • Provision for I.V. Rod on both sides of the bed.
  • Freight saving knock-down construction.

HF1176 - Fowler Bed, Manual, Two Function (with Food Tray)

Standard Features:

  • Fowler Bed with mechanically operated back rest and knee rest by super-smooth crank mechanism.
  • Size: L 2180mm × W 980mm × H 500mm.
  • Removable & interchangeable high quality beautiful ABS engineering plastic head panel and foot panel.
  • Collapsible side railings. (Top bar Aluminium, Vertical bars SS, Bottom pipe epoxy)
  • Equipped with Food Tray.
  • Epoxy coated mild steel frame work and 4 section perforated top.
  • 125mm dia noiseless castors (all with individual brakes)
  • Provision for I.V. Rod on both sides of the bed.
  • Freight saving knock-down construction.

HF1182 - Fowler Bed, Manual, Two Function

Standard Features:

  • Fowler Bed with mechanically operated back rest and knee rest by super-smooth crank mechanism.
  • Size: L 2140mm × W 940mm × H 500mm.
  • Removable & interchangeable high quality beautiful ABS engineering plastic head panel and foot panel. D type Design.
  • Collapsible side railings. (Top bar Aluminium, Vertical bars SS, Bottom pipe epoxy)
  • Epoxy coated mild steel frame work and 4 section perforated top.
  • Molded bed board with ventilated holes.
  • 125mm dia noiseless castors (all with individual brakes)
  • Provision for I.V. Rod on both sides of the bed.
  • Freight saving knock-down construction.
Item Code Type
HF1186 Same as HF1182 but With C type design of head & foot panels. HF1186
HF1188a Same as HF1182 but With N type design of head & foot panels and wire mesh plateform. HF1188

HF1191 - Fowler Bed, Manual, Two Function

Standard Features:

  • Fowler Bed with mechanically operated back rest and knee rest by super-smooth crank mechanism.
  • Size: L 2120mm × W 980mm × H 500mm.
  • Removable & interchangeable high quality beautiful ABS engineering plastic head panel and foot panel.
  • Collapsible side railings. (Top bar Aluminium, Vertical bars SS, Bottom pipe epoxy)
  • Epoxy coated mild steel frame work and 4 section top.
  • 125mm dia noiseless castors (all with individual brakes)
  • Provision for I.V. Rod on both sides of the bed.
  • Freight saving knock-down construction.

HF1196 - Fowler Bed, Manual, Two Function

Standard Features:

  • Fowler Bed with mechanically operated back rest and knee rest by super-smooth crank mechanism.
  • Size: L 2140mm × W 980mm × H 500mm.
  • Removable & interchangeable high quality beautiful ABS engineering plastic head panel and foot panel.
  • Collapsible side railings. (Top bar Aluminium, Vertical bars SS, Bottom pipe epoxy)
  • Epoxy coated mild steel frame work and 4 section perforated top.
  • Mounted on protective stumps.
  • Provision for I.V. Rod on both sides of the bed.
  • Freight saving knock-down construction.

HF1206 - Fowler Bed, Manual, Two Function

Standard Features:

  • Fowler Bed with mechanically operated back rest and knee rest by super-smooth crank mechanism.
  • Size: L 2120mm × W 940mm × H 500mm.
  • Removable & interchangeable high quality beautiful ABS engineering plastic head panel and foot panel.
  • Epoxy coated mild steel frame work and 4 section perforated top.
  • Mounted on protective stumps.
  • Provision for I.V. Rod on both sides of the bed.
  • Freight saving knock-down construction.

HF1709a - Standard Fowler Bed

Standard Features:

  • Standard fowler bed with mechanically operated back rest and knee rest by crank mechanism.
  • Size: 2030 × 900 × 500 mm.
  • Epoxy coated mild steel frame work and 4 section top.
  • Stainless steel head & foot panels.
  • Four swivel castor (all with individual brakes).
  • Provision for I.V. Rod.
  • Freight saving knock-down construction.
Item Code Type
HF1710 Same as HF1709a but without castors

HF1711 - Standard Fowler Bed

Standard Features:

  • Standard fowler bed with mechanically operated back rest and knee rest by crank mechanism.
  • Size: 2030 × 900 × 530 mm.
  • Epoxy coated mild steel frame work and 4 section top.
  • Tubular head & foot bows made of stainless steel.
  • Mounted on protective stumps.
  • Provision for I.V. Rod.
  • Freight saving knock-down construction.
Item Code Type
HF1712 Same as HF1711, but with castor.

HF1725 - Standard Fowler Bed

Standard Features:

  • Standard fowler bed with mechanically operated back rest and knee rest by crank mechanism.
  • Size: 2030 × 900 × 500 mm.
  • Epoxy coated mild steel frame work & 4 section top..
  • Mounted on protective stumps.
  • Provision for I.V. Rod.
  • Freight saving knock-down construction.
Item Code Type
HF1726 Same as HF1725, but with castor.

HF1834 - Fowler Bed, Manual, Two Function (with Provision for Bed Pan)

Standard Features:

  • Fowler Bed with mechanically operated back rest and knee rest by crank mechanism.
  • Size: 2000 × 900 × 500 mm.
  • Provision for Bed pan.
  • Epoxy coated mild steel frame work and 4 section top.
  • Mounted on protective stumps.
  • Provision for I.V. Rod on both sides of the bed.
  • Freight saving knock-down construction.

HF105 - Fowler Bed Deluxe

Standard Features:

  • Fowler bed with detachable SS Frame Head and foot bows with laminated panels.
  • Size: L 2060mm × W 900mm × H 600mm
  • Back rest 0-75º, Knee rest 0-35°
  • Epoxy coated mild steel structure with 4 section mattress platform made up of CRCA M.S. Sheet.
  • 2 Separate crank mechanisms for back rest and knee rest respectively.
  • Provision for I.V. Rod on four locations.
  • 100mm Dia. castors 2 with brake

HF106 - Fowler Bed General

Standard Features:

  • Fowler bed with tubular head and foot bows of unequal height.
  • Size: L 2060mm × W 900mm × H 600mm
  • Back rest 0-75º, Knee rest 0-35°
  • Epoxy coated mild steel structure with 4 section mattress platform made up of CRCA M.S. Sheet.
  • 2 Separate crank mechanisms for back rest and knee rest respectively.
  • Provision for I.V. Rod on four locations.
  • Legs fitted with PVC stumps.

HF105A - Fowler Bed Super Deluxe

Specifications/Details:

  • Fowler bed with detachable Plastic Head and foot bows.
  • Size: L 2060mm × W 900mm × H 600mm
  • Back rest 0-75º, Knee rest 0-35°
  • Epoxy coated mild steel structure with 4 section mattress platform made up of CRCA M.S. Sheet.
  • 2 Separate crank mechanisms for back rest and knee rest respectively.
  • Stainless Steel drop down side rails.
  • Provision for I.V. Rod on four locations.
  • 125mm Dia. castors 2 with brake

HF106A - Fowler Bed Semi Deluxe

Specifications/Details:

  • Fowler bed with detachable SS frame Head and foot bows with laminated panels and roller bumpers.
  • Size: L 2100mm × W 900mm × H 600mm
  • Back rest 0-75º, Knee rest 0-35°
  • Epoxy coated mild steel structure with 4 section mattress platform made up of CRCA M.S. Sheet.
  • 2 Separate crank mechanisms for back rest and knee rest respectively.
  • Stainless Steel drop down side rails.
  • Provision for I.V. Rod on four locations.
  • 125mm Dia. castors 2 with brake
