Infant Radiant Warmer, Open Care System - Apple Series


NIC201a : Infant Radiant Warmer with Fixed Baby Cradle and Drawers with Microprocessor based temperature controller with 4 modes Skin / Air / Manual / Prewarm mode
Standard Specifications for NIC201a
  • Fixed height warmer with attached baby cradle and drawers mounted on 4" (100mm) wheels, 2 with brake.
  • Stainless steel baby tray with water proof, zipped cover mattress of density approx. 21-25 kg/m³
  • Continuous head up/down facility
  • X-Ray cassette holder
  • Collapsible/lockable Side Supports made up of Unbreakable polycarbonate material
  • Slots for sensor and ventilator tubing
  • Side tray for placement of monitor
  • Stainless steel infusion rod with facility to mount Syringe/infusion pump
  • Lower shelf below baby tray to facilitate under surface phototherapy, Facility of 3 drawers for storage
  • Height : 74.5" (1890 mm), Width : 28.0" (710 mm), Length : 39.0" (990 mm)
  • Bed to Floor Height : 37.5" (950 mm)
  • Distance between baby bed and heater: 33" (840 mm)
  • Mattress size: 30" (762 mm) x 20" (508 mm)
  • Height of side panel above baby bed: 5.75" (145 mm)
Performance/Electrical Specifications :
  • Microprocessor based temperature controller with Pre-warm, Manual and Skin Servo modes
  • LED Display of Skin Temp.,Air Temp., Set Temp. (Resolution 0.1°C) & Heater Power %.
  • LCD to display modes of operation, Alarm messages, Skin Temperature in °F and Timer.
  • Thermistor based sensor with Accuracy of +/- 0.2°C (Temp. Calibration not require)
  • Modes of Operation: Skin Servo, Air, Manual and Pre-Warm
  • Keypad lock facility
  • Skin mode: Temperature range: 34 to 38°C , Resolution : 0.1°C
  • Air mode: Temperature range: Room temp. to 39°C , Resolution : 0.1°C
  • Manual mode: Adjustable Heater Power 0 to 100% (with an increment of 5%), Time duration:15mins
  • Pre-warm mode: To pre-warm the cradle before baby is placed on the bed. (No alarm will be activated during Prewarm mode) Adjustable Heater Power 0 to 25% (with an increment of 5%), Time duration:30mins
  • Overhead heater box: Swivelling, Consists of Ceramic heater (650 Watts) placed in parabolic reflector with a safety grill & Halogen observation light (12V/50W) for observing the baby
  • Operating Voltage: 220-240 VAC, 50Hz, Power: 800W (Max.)
  • Alarm: Audio alarm with 10 minute mute facility & Visual alarms with message on LCD as follows
Alarm Condition Alarm Messages on LCD
Skin Sensor is unplugged /Faulty Skin Sensor Fail
Air Sensor is unplugged /Faulty Air Sensor Fail
Measured skin temperature higher than set temperature by 1.0°C Skin Temp. High
Measured skin temperature lower than set temperature by 1.0°C Skin Temp. Low
Measured skin temperature higher than 38.0°C (With cut-off) Skin Over Range
Measured skin temperature lower than 34.0°C Skin Under Range
Measured air temperature higher than set temperature by 1.5°C Air Temp. High
Measured air temperature lower than set temperature by 3.0°C Air Temp. Low
Measured air temperature higher than 39.0°C (With cut-off) Air Over Range
Heater power is 100% for more than 15mins Chk Sens Position
Heater is unplugged or faulty Heater Open
Heater Power drive fail/uncontrollable Chk. Pwr. Drive
Power Fail Alarm: Audio with LED indicator

NIC211a : Infant Radiant Warmer with Fixed Baby Cradle and Drawers with Microprocessor based temperature controller with 3 modes Skin / Manual / Prewarm mode
Standard Specifications for NIC211a
  • Fixed height warmer with attached baby cradle and drawers mounted on 4" (100mm) wheels, 2 with brake.
  • Stainless steel baby tray with water proof, zipped cover mattress of density approx. 21-25 kg/m³
  • Continuous head up/down facility
  • X-Ray cassette holder
  • Collapsible/lockable Side Supports made up of Unbreakable polycarbonate material
  • Slots for sensor and ventilator tubing
  • Side tray for placement of monitor
  • Stainless steel infusion rod with facility to mount Syringe/infusion pump
  • Lower shelf below baby tray to facilitate under surface phototherapy, Facility of 3 drawers for storage
  • Height : 74.5" (1890 mm), Width : 28.0" (710 mm), Length : 39.0" (990 mm)
  • Bed to Floor Height : 37.5" (950 mm)
  • Distance between baby bed and heater: 33" (840 mm)
  • Mattress size: 30" (762 mm) x 20" (508 mm)
  • Height of side panel above baby bed: 5.75" (145 mm)
Performance/Electrical Specifications :
  • Microprocessor based temperature controller with Pre-warm, Manual and Skin Servo modes
  • LED Display of Skin Temp., Set Temp. (Resolution 0.1°C) & Heater Power %.
  • LCD to display modes of operation, Alarm messages, Skin Temperature in °F and Timer.
  • Thermistor based sensor with Accuracy of +/- 0.2°C (Temp. Calibration not require)
  • Modes of Operation: Skin Servo, Manual and Pre-Warm
  • Keypad lock facility
  • Skin mode: Temperature range: 34 to 38°C , Resolution : 0.1°C
  • Manual mode: Adjustable Heater Power 0 to 100% (with an increment of 5%), Time duration:15mins
  • Pre-warm mode: To pre-warm the cradle before baby is placed on the bed. (No alarm will be activated during Prewarm mode). Adjustable Heater Power 0 to 25% (with an increment of 5%), Time duration:30mins
  • Overhead heater box: Swivelling, Consists of Ceramic heater (650 Watts) placed in parabolic reflector with a safety grill & Halogen observation light (12V/50W) for observing the baby
  • Operating Voltage: 220-240 VAC, 50Hz, Power: 800W (Max.)
  • Alarm: Audio alarm with 10 minute mute facility & Visual alarms with message on LCD as follows
Alarm Condition Alarm Messages on LCD
Skin Sensor is unplugged /Faulty Skin Sensor Fail
Measured skin temperature higher than set temperature by 1.0°C Skin Temp. High
Measured skin temperature lower than set temperature by 1.0°C Skin Temp. Low
Measured skin temperature higher than 38.0°C (With cut-off) Skin Over Range
Measured skin temperature lower than 34.0°C Skin Under Range
Heater power is 100% for more than 15mins Chk Sens Position
Heater is unplugged or faulty Heater Open
Heater Power drive fail/uncontrollable Chk. Pwr. Drive
Power Fail Alarm: Audio with LED indicator

NIC202a : Infant Radiant Warmer with Fixed Baby Cradle and Drawers with Microprocessor based temperature controller with 4 modes Skin / Air / Manual / Prewarm mode
Standard Specifications for NIC202a
  • Fixed height warmer with attached baby cradle and drawers mounted on 4" (100mm) wheels, 2 with brake.
  • Stainless steel baby tray with water proof, zipped cover mattress of density approx. 21-25 kg/m³
  • Continuous head up/down facility
  • X-Ray cassette holder
  • Collapsible/lockable Side Supports made up of Unbreakable polycarbonate material
  • Slots for sensor and ventilator tubing
  • Side tray for placement of monitor
  • Stainless steel infusion rod with facility to mount Syringe/infusion pump
  • Lower shelf below baby tray to facilitate under surface phototherapy.
  • Height : 74.5" (1890 mm), Width : 28.0" (710 mm), Length : 39.0" (990 mm)
  • Bed to Floor Height : 37.5" (950 mm)
  • Distance between baby bed and heater: 33" (840 mm)
  • Mattress size: 30" (762 mm) x 20" (508 mm)
  • Height of side panel above baby bed: 5.75" (145 mm)
Performance/Electrical Specifications :
  • Microprocessor based temperature controller with Pre-warm, Manual and Skin Servo modes
  • LED Display of Skin Temp.,Air Temp., Set Temp. (Resolution 0.1°C) & Heater Power %.
  • LCD to display modes of operation, Alarm messages, Skin Temperature in °F and Timer.
  • Thermistor based sensor with Accuracy of +/- 0.2°C (Temp. Calibration not require)
  • Modes of Operation: Skin Servo, Air, Manual and Pre-Warm
  • Keypad lock facility
  • Skin mode: Temperature range: 34 to 38°C , Resolution : 0.1°C
  • Air mode: Temperature range: Room temp. to 39°C , Resolution : 0.1°C
  • Manual mode: Adjustable Heater Power 0 to 100% (with an increment of 5%), Time duration:15mins
  • Pre-warm mode: To pre-warm the cradle before baby is placed on the bed. (No alarm will be activated during Prewarm mode) Adjustable Heater Power 0 to 25% (with an increment of 5%), Time duration:30mins
  • Overhead heater box: Swivelling, Consists of Ceramic heater (650 Watts) placed in parabolic reflector with a safety grill & Halogen observation light (12V/50W) for observing the baby
  • Operating Voltage: 220-240 VAC, 50Hz, Power: 800W (Max.)
  • Alarm: Audio alarm with 10 minute mute facility & Visual alarms with message on LCD as follows
Alarm Condition Alarm Messages on LCD
Skin Sensor is unplugged /Faulty Skin Sensor Fail
Air Sensor is unplugged /Faulty Air Sensor Fail
Measured skin temperature higher than set temperature by 1.0°C Skin Temp. High
Measured skin temperature lower than set temperature by 1.0°C Skin Temp. Low
Measured skin temperature higher than 38.0°C (With cut-off) Skin Over Range
Measured skin temperature lower than 34.0°C Skin Under Range
Measured air temperature higher than set temperature by 1.5°C Air Temp. High
Measured air temperature lower than set temperature by 3.0°C Air Temp. Low
Measured air temperature higher than 39.0°C (With cut-off) Air Over Range
Heater power is 100% for more than 15mins Chk Sens Position
Heater is unplugged or faulty Heater Open
Heater Power drive fail/uncontrollable Chk. Pwr. Drive
Power Fail Alarm: Audio with LED indicator

NIC212a : Infant Radiant Warmer with Fixed Baby Cradle and Drawers with Microprocessor based temperature controller with 3 modes Skin / Manual / Prewarm mode
Standard Specifications for NIC212a
  • Fixed height warmer with attached baby cradle mounted on 4" (100mm) wheels, 2 with brake.
  • Stainless steel baby tray with water proof, zipped cover mattress of density approx. 21-25 kg/m³
  • Continuous head up/down facility
  • X-Ray cassette holder
  • Collapsible/lockable Side Supports made up of Unbreakable polycarbonate material
  • Slots for sensor and ventilator tubing
  • Side tray for placement of monitor
  • Stainless steel infusion rod with facility to mount Syringe/infusion pump
  • Lower shelf below baby tray to facilitate under surface phototherapy.
  • Height : 74.5" (1890 mm), Width : 28.0" (710 mm), Length : 39.0" (990 mm)
  • Bed to Floor Height : 37.5" (950 mm)
  • Distance between baby bed and heater: 33" (840 mm)
  • Mattress size: 30" (762 mm) x 20" (508 mm)
  • Height of side panel above baby bed: 5.75" (145 mm)
Performance/Electrical Specifications :
  • Microprocessor based temperature controller with Pre-warm, Manual and Skin Servo modes
  • LED Display of Skin Temp., Set Temp. (Resolution 0.1°C) & Heater Power %.
  • LCD to display modes of operation, Alarm messages, Skin Temperature in °F and Timer.
  • Thermistor based sensor with Accuracy of +/- 0.2°C (Temp. Calibration not require)
  • Modes of Operation: Skin Servo, Manual and Pre-Warm
  • Keypad lock facility
  • Skin mode: Temperature range: 34 to 38°C , Resolution : 0.1°C
  • Manual mode: Adjustable Heater Power 0 to 100% (with an increment of 5%), Time duration:15mins
  • Pre-warm mode: To pre-warm the cradle before baby is placed on the bed. (No alarm will be activated during Prewarm mode). Adjustable Heater Power 0 to 25% (with an increment of 5%), Time duration:30mins
  • Overhead heater box: Swivelling, Consists of Ceramic heater (650 Watts) placed in parabolic reflector with a safety grill & Halogen observation light (12V/50W) for observing the baby
  • Operating Voltage: 220-240 VAC, 50Hz, Power: 800W (Max.)
  • Alarm: Audio alarm with 10 minute mute facility & Visual alarms with message on LCD as follows
Alarm Condition Alarm Messages on LCD
Skin Sensor is unplugged /Faulty Skin Sensor Fail
Measured skin temperature higher than set temperature by 1.0°C Skin Temp. High
Measured skin temperature lower than set temperature by 1.0°C Skin Temp. Low
Measured skin temperature higher than 38.0°C (With cut-off) Skin Over Range
Measured skin temperature lower than 34.0°C Skin Under Range
Heater power is 100% for more than 15mins Chk Sens Position
Heater is unplugged or faulty Heater Open
Heater Power drive fail/uncontrollable Chk. Pwr. Drive
Power Fail Alarm: Audio with LED indicator

NIC203a : Infant Radiant Warmer with Detachable Baby Cradle with Microprocessor based temperature controller with 4 modes Skin / Air / Manual / Prewarm mode
Standard Specifications
  • Fixed height warmer with detachable baby cradle mounted on 4" (100mm) wheels, 2 with brake.
  • Stainless steel baby tray with water proof, zipped cover mattress of density approx. 21-25 kg/m³
  • Continuous head up/down facility
  • X-Ray cassette holder
  • Collapsible/lockable Side Supports made up of Unbreakable polycarbonate material
  • Slots for sensor and ventilator tubing
  • Side tray for placement of monitor
  • Stainless steel infusion rod with facility to mount Syringe/infusion pump
  • Lower shelf below baby tray to facilitate under surface phototherapy.
  • Height : 74.5" (1890 mm), Width : 28.0" (710 mm), Length : 39.0" (990 mm)
  • Bed to Floor Height : 37.5" (950 mm)
  • Distance between baby bed and heater: 33" (840 mm)
  • Mattress size: 30" (762 mm) x 20" (508 mm)
  • Height of side panel above baby bed: 5.75" (145 mm)
Performance/Electrical Specifications :
  • Microprocessor based temperature controller with Pre-warm, Manual and Skin Servo modes
  • LED Display of Skin Temp., Air Temp., Set Temp. (Resolution 0.1°C) & Heater Power %.
  • LCD to display modes of operation, Alarm messages, Skin Temperature in °F and Timer.
  • Thermistor based sensor with Accuracy of +/- 0.2°C (Temp. Calibration not require)
  • Modes of Operation: Skin Servo, Manual and Pre-Warm
  • Keypad lock facility
  • Skin mode: Temperature range: 34 to 38°C , Resolution : 0.1°C
  • Manual mode: Adjustable Heater Power 0 to 100% (with an increment of 5%), Time duration:15mins
  • Pre-warm mode: To pre-warm the cradle before baby is placed on the bed. (No alarm will be activated during Prewarm mode). Adjustable Heater Power 0 to 25% (with an increment of 5%), Time duration:30mins
  • Overhead heater box: Swivelling, Consists of Ceramic heater (650 Watts) placed in parabolic reflector with a safety grill & Halogen observation light (12V/50W) for observing the baby
  • Operating Voltage: 220-240 VAC, 50Hz, Power: 800W (Max.)
  • Alarm: Audio alarm with 10 minute mute facility & Visual alarms with message on LCD as follows
Alarm Condition Alarm Messages on LCD
Skin Sensor is unplugged /Faulty Skin Sensor Fail
Air Sensor is unplugged /Faulty Air Sensor Fail
Measured skin temperature higher than set temperature by 1.0°C Skin Temp. High
Measured skin temperature lower than set temperature by 1.0°C Skin Temp. Low
Measured skin temperature higher than 38.0°C (With cut-off) Skin Over Range
Measured skin temperature lower than 34.0°C Skin Under Range
Measured air temperature higher than set temperature by 1.5°C Air Temp. High
Measured air temperature lower than set temperature by 3.0°C Air Temp. Low
Measured air temperature higher than 39.0°C (With cut-off) Air Over Range
Heater power is 100% for more than 15mins Chk Sens Position
Heater is unplugged or faulty Heater Open
Heater Power drive fail/uncontrollable Chk. Pwr. Drive
Power Fail Alarm: Audio with LED indicator

NIC213a : Infant Radiant Warmer with Detachable Baby Cradle and Drawers with Microprocessor based temperature controller with 3 modes Skin / Manual / Prewarm mode
Standard Specifications
  • Fixed height warmer with detachable baby cradle mounted on 4" (100mm) wheels, 2 with brake.
  • Stainless steel baby tray with water proof, zipped cover mattress of density approx. 21-25 kg/m³
  • Continuous head up/down facility
  • X-Ray cassette holder
  • Collapsible/lockable Side Supports made up of Unbreakable polycarbonate material
  • Slots for sensor and ventilator tubing
  • Side tray for placement of monitor
  • Stainless steel infusion rod with facility to mount Syringe/infusion pump
  • Lower shelf below baby tray to facilitate under surface phototherapy.
  • Height : 74.5" (1890 mm), Width : 28.0" (710 mm), Length : 39.0" (990 mm)
  • Bed to Floor Height : 37.5" (950 mm)
  • Distance between baby bed and heater: 33" (840 mm)
  • Mattress size: 30" (762 mm) x 20" (508 mm)
  • Height of side panel above baby bed: 5.75" (145 mm)
Performance/Electrical Specifications :
  • Microprocessor based temperature controller with Pre-warm, Manual and Skin Servo modes
  • LED Display of Skin Temp., Set Temp. (Resolution 0.1°C) & Heater Power %.
  • LCD to display modes of operation, Alarm messages, Skin Temperature in °F and Timer.
  • Thermistor based sensor with Accuracy of +/- 0.2°C (Temp. Calibration not require)
  • Modes of Operation: Skin Servo, Manual and Pre-Warm
  • Keypad lock facility
  • Skin mode: Temperature range: 34 to 38°C , Resolution : 0.1°C
  • Manual mode: Adjustable Heater Power 0 to 100% (with an increment of 5%), Time duration:15mins
  • Pre-warm mode: To pre-warm the cradle before baby is placed on the bed. (No alarm will be activated during Prewarm mode). Adjustable Heater Power 0 to 25% (with an increment of 5%), Time duration:30mins
  • Overhead heater box: Swivelling, Consists of Ceramic heater (650 Watts) placed in parabolic reflector with a safety grill & Halogen observation light (12V/50W) for observing the baby
  • Operating Voltage: 220-240 VAC, 50Hz, Power: 800W (Max.)
  • Alarm: Audio alarm with 10 minute mute facility & Visual alarms with message on LCD as follows
Alarm Condition Alarm Messages on LCD
Skin Sensor is unplugged /Faulty Skin Sensor Fail
Measured skin temperature higher than set temperature by 1.0°C Skin Temp. High
Measured skin temperature lower than set temperature by 1.0°C Skin Temp. Low
Measured skin temperature higher than 38.0°C (With cut-off) Skin Over Range
Measured skin temperature lower than 34.0°C Skin Under Range
Heater power is 100% for more than 15mins Chk Sens Position
Heater is unplugged or faulty Heater Open
Heater Power drive fail/uncontrollable Chk. Pwr. Drive
Power Fail Alarm: Audio with LED indicator

NIC205 : Infant Radiant Warmer with Fixed Baby Cradle with Microprocessor based temperature controller with 4 modes Skin / Air / Manual / Prewarm mode
Standard Specifications
  • Fixed height warmer with attachable baby cradle and drawers mounted on 4" (100mm) wheels, 2 with brake.
  • Stainless steel baby tray with water proof, zipped cover mattress of density approx. 21-25 kg/m³
  • Continuous head up/down facility
  • X-Ray cassette holder
  • Collapsible/lockable Side Supports made up of Unbreakable polycarbonate material
  • Slots for sensor and ventilator tubing
  • Side tray for placement of monitor
  • Stainless steel infusion rod with facility to mount Syringe/infusion pump
  • Lower shelf below baby tray to facilitate under surface phototherapy, Facility of 3 drawers for storage
  • Height : 74.5" (1890 mm), Width : 28.0" (710 mm), Length : 39.0" (990 mm)
  • Bed to Floor Height : 37.5" (950 mm)
  • Distance between baby bed and heater: 33" (840 mm)
  • Mattress size: 30" (762 mm) x 20" (508 mm)
  • Height of side panel above baby bed: 5.75" (145 mm)
Performance/Electrical Specifications :
  • Microprocessor based temperature controller with Pre-warm, Manual and Skin Servo modes
  • LED Display of Skin Temp., Air Temp., Set Temp. (Resolution 0.1°C) & Heater Power %.
  • LCD to display modes of operation, Alarm messages, Skin Temperature in °F and Timer.
  • Thermistor based sensor with Accuracy of +/- 0.2°C (Temp. Calibration not require)
  • Modes of Operation: Skin Servo, Air, Manual and Pre-Warm
  • Keypad lock facility
  • Skin mode: Temperature range: 34 to 38°C , Resolution : 0.1°C
  • Air mode: Temperature range: Room temp. to 39°C , Resolution : 0.1°C
  • Manual mode: Adjustable Heater Power 0 to 100% (with an increment of 5%), Time duration:15mins
  • Pre-warm mode: To pre-warm the cradle before baby is placed on the bed. (No alarm will be activated during Prewarm mode). Adjustable Heater Power 0 to 25% (with an increment of 5%), Time duration:30mins
  • Overhead heater box: Swivelling, Consists of Ceramic heater (650 Watts) placed in parabolic reflector with a safety grill & Halogen observation light (12V/50W) for observing the baby
  • Operating Voltage: 220-240 VAC, 50Hz, Power: 800W (Max.)
  • Alarm: Audio alarm with 10 minute mute facility & Visual alarms with message on LCD as follows
Alarm Condition Alarm Messages on LCD
Skin Sensor is unplugged /Faulty Skin Sensor Fail
Air Sensor is unplugged /Faulty Air Sensor Fail
Measured skin temperature higher than set temperature by 1.0°C Skin Temp. High
Measured skin temperature lower than set temperature by 1.0°C Skin Temp. Low
Measured skin temperature higher than 38.0°C (With cut-off) Skin Over Range
Measured skin temperature lower than 34.0°C Skin Under Range
Measured air temperature higher than set temperature by 1.5°C Air Temp. High
Measured air temperature lower than set temperature by 3.0°C Air Temp. Low
Measured air temperature higher than 39.0°C (With cut-off) Air Over Range
Heater power is 100% for more than 15mins Chk Sens Position
Heater is unplugged or faulty Heater Open
Heater Power drive fail/uncontrollable Chk. Pwr. Drive
Power Fail Alarm: Audio with LED indicator

NIC207 : Infant Radiant Warmer with Fixed Baby Cradle with Microprocessor based temperature controller with 4 modes Skin / Air / Manual / Prewarm mode
Standard Specifications
  • Fixed height warmer with attached baby cradle mounted on 4" (100mm) wheels, 2 with brake.
  • Stainless steel baby tray with water proof, zipped cover mattress of density approx. 21-25 kg/m³
  • Continuous head up/down facility
  • X-Ray cassette holder
  • Collapsible/lockable Side Supports made up of Unbreakable polycarbonate material
  • Slots for sensor and ventilator tubing
  • Side tray for placement of monitor
  • Stainless steel infusion rod with facility to mount Syringe/infusion pump
  • Lower shelf below baby tray to facilitate under surface phototherapy.
  • Height : 74.5" (1890 mm), Width : 28.0" (710 mm), Length : 39.0" (990 mm)
  • Bed to Floor Height : 37.5" (950 mm)
  • Distance between baby bed and heater: 33" (840 mm)
  • Mattress size: 30" (762 mm) x 20" (508 mm)
  • Height of side panel above baby bed: 5.75" (145 mm)
Performance/Electrical Specifications :
  • Microprocessor based temperature controller with Pre-warm, Manual and Skin Servo modes
  • LED Display of Skin Temp., Air Temp., Set Temp. (Resolution 0.1°C) & Heater Power %.
  • LCD to display modes of operation, Alarm messages, Skin Temperature in °F and Timer.
  • Thermistor based sensor with Accuracy of +/- 0.2°C (Temp. Calibration not require)
  • Modes of Operation: Skin Servo, Air, Manual and Pre-Warm
  • Keypad lock facility
  • Skin mode: Temperature range: 34 to 38°C , Resolution : 0.1°C
  • Air mode: Temperature range: Room temp. to 39°C , Resolution : 0.1°C
  • Manual mode: Adjustable Heater Power 0 to 100% (with an increment of 5%), Time duration:15mins
  • Pre-warm mode: To pre-warm the cradle before baby is placed on the bed. (No alarm will be activated during Prewarm mode). Adjustable Heater Power 0 to 25% (with an increment of 5%), Time duration:30mins
  • Overhead heater box: Swivelling, Consists of Ceramic heater (650 Watts) placed in parabolic reflector with a safety grill & Halogen observation light (12V/50W) for observing the baby
  • Operating Voltage: 220-240 VAC, 50Hz, Power: 800W (Max.)
  • Alarm: Audio alarm with 10 minute mute facility & Visual alarms with message on LCD as follows
Alarm Condition Alarm Messages on LCD
Skin Sensor is unplugged /Faulty Skin Sensor Fail
Air Sensor is unplugged /Faulty Air Sensor Fail
Measured skin temperature higher than set temperature by 1.0°C Skin Temp. High
Measured skin temperature lower than set temperature by 1.0°C Skin Temp. Low
Measured skin temperature higher than 38.0°C (With cut-off) Skin Over Range
Measured skin temperature lower than 34.0°C Skin Under Range
Measured air temperature higher than set temperature by 1.5°C Air Temp. High
Measured air temperature lower than set temperature by 3.0°C Air Temp. Low
Measured air temperature higher than 39.0°C (With cut-off) Air Over Range
Heater power is 100% for more than 15mins Chk Sens Position
Heater is unplugged or faulty Heater Open
Heater Power drive fail/uncontrollable Chk. Pwr. Drive
Power Fail Alarm: Audio with LED indicator

NIC206 : Infant Radiant Warmer with Fixed Baby Cradle and Drawers with Microprocessor based temperature controller with 3 modes Skin / Manual / Prewarm mode
Standard Specifications
  • Fixed height warmer with attachable baby cradle and drawers mounted on 4" (100mm) wheels, 2 with brake.
  • Stainless steel baby tray with water proof, zipped cover mattress of density approx. 21-25 kg/m³
  • Continuous head up/down facility
  • X-Ray cassette holder
  • Collapsible/lockable Side Supports made up of Unbreakable polycarbonate material
  • Slots for sensor and ventilator tubing
  • Side tray for placement of monitor
  • Stainless steel infusion rod with facility to mount Syringe/infusion pump
  • Lower shelf below baby tray to facilitate under surface phototherapy, Facility of 3 drawers for storage
  • Height : 74.5" (1890 mm), Width : 28.0" (710 mm), Length : 39.0" (990 mm)
  • Bed to Floor Height : 37.5" (950 mm)
  • Distance between baby bed and heater: 33" (840 mm)
  • Mattress size: 30" (762 mm) x 20" (508 mm)
  • Height of side panel above baby bed: 5.75" (145 mm)
Performance/Electrical Specifications :
  • Microprocessor based temperature controller with Pre-warm, Manual and Skin Servo modes
  • LED Display of Skin Temp., Set Temp. (Resolution 0.1°C) & Heater Power %.
  • LCD to display modes of operation, Alarm messages, Skin Temperature in °F and Timer.
  • Thermistor based sensor with Accuracy of +/- 0.2°C (Temp. Calibration not require)
  • Modes of Operation: Skin Servo, Manual and Pre-Warm
  • Keypad lock facility
  • Skin mode: Temperature range: 34 to 38°C , Resolution : 0.1°C
  • Manual mode: Adjustable Heater Power 0 to 100% (with an increment of 5%), Time duration:15mins
  • Pre-warm mode: To pre-warm the cradle before baby is placed on the bed. (No alarm will be activated during Prewarm mode). Adjustable Heater Power 0 to 25% (with an increment of 5%), Time duration:30mins
  • Overhead heater box: Swivelling, Consists of Ceramic heater (650 Watts) placed in parabolic reflector with a safety grill & Halogen observation light (12V/50W) for observing the baby
  • Operating Voltage: 220-240 VAC, 50Hz, Power: 800W (Max.)
  • Alarm: Audio alarm with 10 minute mute facility & Visual alarms with message on LCD as follows
Alarm Condition Alarm Messages on LCD
Skin Sensor is unplugged /Faulty Skin Sensor Fail
Measured skin temperature higher than set temperature by 1.0°C Skin Temp. High
Measured skin temperature lower than set temperature by 1.0°C Skin Temp. Low
Measured skin temperature higher than 38.0°C (With cut-off) Skin Over Range
Measured skin temperature lower than 34.0°C Skin Under Range
Heater power is 100% for more than 15mins Chk Sens Position
Heater is unplugged or faulty Heater Open
Heater Power drive fail/uncontrollable Chk. Pwr. Drive
Power Fail Alarm: Audio with LED indicator

NIC208 : Infant Radiant Warmer with Fixed Baby Cradle with Microprocessor based temperature controller with 3 modes Skin / Manual / Prewarm mode
Standard Specifications
  • Fixed height with attached baby cradle mounted on 4" (100mm) wheels, 2 with brake.
  • Stainless steel baby tray with water proof, zipped cover mattress of density approx. 21-25 kg/m³
  • Continuous head up/down facility
  • X-Ray cassette holder
  • Collapsible/lockable Side Supports made up of Unbreakable polycarbonate material
  • Slots for sensor and ventilator tubing
  • Side tray for placement of monitor
  • Stainless steel infusion rod with facility to mount Syringe/infusion pump
  • Lower shelf below baby tray to facilitate under surface phototherapy.
  • Height : 74.5" (1890 mm), Width : 28.0" (710 mm), Length : 39.0" (990 mm)
  • Bed to Floor Height : 37.5" (950 mm)
  • Distance between baby bed and heater: 33" (840 mm)
  • Mattress size: 30" (762 mm) x 20" (508 mm)
  • Height of side panel above baby bed: 5.75" (145 mm)
Performance/Electrical Specifications :
  • Microprocessor based temperature controller with Pre-warm, Manual and Skin Servo modes
  • LED Display of Skin Temp., Air Temp., Set Temp. (Resolution 0.1°C) & Heater Power %.
  • LCD to display modes of operation, Alarm messages, Skin Temperature in °F and Timer.
  • Thermistor based sensor with Accuracy of +/- 0.2°C (Temp. Calibration not require)
  • Modes of Operation: Skin Servo, Manual and Pre-Warm
  • Keypad lock facility
  • Skin mode: Temperature range: 34 to 38°C , Resolution : 0.1°C
  • Manual mode: Adjustable Heater Power 0 to 100% (with an increment of 5%), Time duration:15mins
  • Pre-warm mode: To pre-warm the cradle before baby is placed on the bed. (No alarm will be activated during Prewarm mode). Adjustable Heater Power 0 to 25% (with an increment of 5%), Time duration:30mins
  • Overhead heater box: Swivelling, Consists of Ceramic heater (650 Watts) placed in parabolic reflector with a safety grill & Halogen observation light (12V/50W) for observing the baby
  • Operating Voltage: 220-240 VAC, 50Hz, Power: 800W (Max.)
  • Alarm: Audio alarm with 10 minute mute facility & Visual alarms with message on LCD as follows
Alarm Condition Alarm Messages on LCD
Skin Sensor is unplugged /Faulty Skin Sensor Fail
Measured skin temperature higher than set temperature by 1.0°C Skin Temp. High
Measured skin temperature lower than set temperature by 1.0°C Skin Temp. Low
Measured skin temperature higher than 38.0°C (With cut-off) Skin Over Range
Measured skin temperature lower than 34.0°C Skin Under Range
Heater power is 100% for more than 15mins Chk Sens Position
Heater is unplugged or faulty Heater Open
Heater Power drive fail/uncontrollable Chk. Pwr. Drive
Power Fail Alarm: Audio with LED indicator

NIC722 : Infant Radiant Warmer with Fixed Baby Cradle & Drawers with Microprocessor based temperature controller with 4 mode Skin / Air / Manual / Prewarm
Technical Specification:
Heater Box
  • Consists of Ceramic Infra Red Heater 650Watts,
  • The source box can be swivelled to take X-ray
  • Due to temp. insulated cover on the heater box, its exterior surface remains cool even after long run
  • The construction of the stainless steel reflector and Guard rail is such that the complete cleaning of heater & reflector is possible without any electrical shock hazards
Halogen Examination Lamp (12 Volts, 50 Watts)
  • To Provide accurate assessment of Infant colour and sufficient illumination during procedures
Baby Tray (Stainless Steel)
  • Clear acrylic collapsible side panels
  • Stainless steel baby tray with transparent slot to incorporate the facility of under surface phototherapy
  • Acrylic tray and cushion mattress with head up/down facility
  • Acrylic X-ray tray with X-ray guide for positioning the cassette
  • The design aspects also allow ease of dismantling baby care area during cleaning or fumigation
Essential Attachments
  • Lower Shelf and 3 Drawer Storage Cabinet
  • Side Mounted Monitor tray, Pole for Syringe Pump / Infusion Pump
  • S.S. IV Stand.
Micro Computer Based Temp. Controllers
  • To Prove Highest Degree of Accuracy of maintenance of baby’s body Temperature.
Sensors
  • Thermistor type sensor with Accuracy: ± 0.2°C
Alarms
  • Audio alarm mute facility.
  • Mute timing adjustable
Displays
  • 1” Bright 7 segment LED’s (3 nos.) for Skin temp.
  • 0.5” Bright 7 segment LED’s (3 nos.) for Set temp.
  • 0.5” Bright 7 segment LED’s (3 nos.) for Heater Power%.
  • 0.5” Bright 7 segment LED’s (3 nos.) for Air temp.
  • Resolution: 0.1°C
Status: On LCD
  • Control Mode
  • Constant Skin temp in ° Fahrenheit.
  • Timer: Down Timer / APGAR Timer
  • Alarm Messages for
    • Skin Over temperature: Temp > 38.0°C
    • Skin Under temperature: Temp < 34.0°C
    • Skin Positive band: Temp > Set Temp by 1.0°C
    • Skin Negative Band: Temp < Set Temp by 1.0°C
    • Air Over temperature: Temp > 39.0°C
    • Air Under temperature: Temp < 20.0°C
    • Air Positive band: Temp > Set Temp by 1.5°C
    • Air Negative Band: Temp > Set Temp by 3.0°C
    • Heater Failure: Heater connection is failed/damage/faulty
    • System Failure: Fluctuation of voltage supply.
    • Check Sensor position: No proper voltage supply

NIC723 : Infant Radiant Warmer with Fixed Baby Cradle & Drawers with Microprocessor based temperature controller with 3 mode Skin / Manual / Prewarm
Technical Specification:
Heater Box
  • Consists of Ceramic Infra Red Heater 650Watts,
  • The source box can be swivelled to take X-ray
  • Due to temp. insulated cover on the heater box, its exterior surface remains cool even after long run
  • The construction of the stainless steel reflector and Guard rail is such that the complete cleaning of heater & reflector is possible without any electrical shock hazards
Halogen Examination Lamp (12 Volts, 50 Watts)
  • To Provide accurate assessment of Infant colour and sufficient illumination during procedures
Baby Tray (Stainless Steel)
  • Clear acrylic collapsible side panels
  • Stainless steel baby tray with transparent slot to incorporate the facility of under surface phototherapy
  • Acrylic tray and cushion mattress with head up/down facility
  • Acrylic X-ray tray with X-ray guide for positioning the cassette
  • The design aspects also allow ease of dismantling baby care area during cleaning or fumigation
Essential Attachments
  • Lower Shelf and 3 Drawer Storage Cabinet
  • Side Mounted Monitor tray, Pole for Syringe Pump / Infusion Pump
  • S.S. IV Stand.
Micro Computer Based Temp. Controllers
  • To Prove Highest Degree of Accuracy of maintenance of baby’s body Temperature.
Sensors
  • Thermistor type sensor with Accuracy: ± 0.2°C
Alarms
  • Audio alarm mute facility.
  • Mute timing adjustable
Range
  • Skin Mode: 30.0°C to 38.0°C
  • Manual Mode: Vary Heater Power % from 0% to 100% with increment of5%
  • Time duration (Manual mode): 15 mins (factory default)
  • Prewarm mode: Vary Heater Power % from 0% to 25% with increment of5%
  • Time duration (Manual mode): 30 mins (factory default)
Displays
  • 1” Bright 7 segment LED’s (3 nos.) for Skin temp.
  • 0.5” Bright 7 segment LED’s (3 nos.) for Set temp.
  • 0.5” Bright 7 segment LED’s (3 nos.) for Heater Power%.
  • Resolution: 0.1°C
Status: On LCD
  • Control Mode
  • Constant Skin temp in ° Fahrenheit.
  • Timer: Down Timer / APGAR Timer
  • Alarm Messages for
    • Skin Over temperature: Temp > 38.0°C
    • Skin Under temperature: Temp < 34.0°C
    • Skin Positive band: Temp > Set Temp by 1.0°C
    • Skin Negative Band: Temp < Set Temp by 1.0°C
    • Heater Failure: Heater connection is failed/damage/faulty
    • System Failure: Fluctuation of voltage supply.
    • Check Sensor position: No proper voltage supply

NIC732 : Infant Radiant Warmer with Fixed Baby Cradle with Microprocessor based temperature controller with 4 mode Skin / Air / Manual / Prewarm
Technical Specification:
Heater Box
  • Consists of Ceramic Infra Red Heater 650Watts,
  • The source box can be swivelled to take X-ray
  • Due to temp. insulated cover on the heater box, its exterior surface remains cool even after long run
  • The construction of the stainless steel reflector and Guard rail is such that the complete cleaning of heater & reflector is possible without any electrical shock hazards
Halogen Examination Lamp (12 Volts, 50 Watts)
  • To Provide accurate assessment of Infant colour and sufficient illumination during procedures
Baby Tray (Stainless Steel)
  • Clear acrylic collapsible side panels
  • Stainless steel baby tray with transparent slot to incorporate the facility of under surface phototherapy
  • Acrylic tray and cushion mattress with head up/down facility
  • Acrylic X-ray tray with X-ray guide for positioning the cassette
  • The design aspects also allow ease of dismantling baby care area during cleaning or fumigation
Essential Attachments
  • Lower Shelves
  • Side Mounted Monitor tray, Pole for Syringe Pump / Infusion Pump
  • S.S. IV Stand.
Micro Computer Based Temp. Controllers
  • To Prove Highest Degree of Accuracy of maintenance of baby’s body Temperature.
Sensors
  • Thermistor type sensor with Accuracy: ± 0.2°C
Alarms
  • Audio alarm mute facility.
  • Mute timing adjustable
Range
  • Skin Mode: 30.0°C to 38.0°C
  • Air Mode: Room temp. 20.0°C to 39.0°C
  • Manual Mode: Vary Heater Power % from 0% to 100% with increment of 5%
  • Time duration (Manual mode): 15 mins (factory default)
  • Prewarm mode: Vary Heater Power % from 0% to 25% with increment of 5%
  • Time duration (Manual mode): 30 mins (factory default)
Displays
  • 1” Bright 7 segment LED’s (3 nos.) for Skin temp.
  • 0.5” Bright 7 segment LED’s (3 nos.) for Set temp.
  • 0.5” Bright 7 segment LED’s (3 nos.) for Heater Power%.
  • 0.5” Bright 7 segment LED’s (3 nos.) for Air temp.
  • Resolution: 0.1°C
Status: On LCD
  • Control Mode
  • Constant Skin temp in ° Fahrenheit.
  • Timer: Down Timer / APGAR Timer
  • Alarm Messages for
    • Skin Over temperature: Temp > 38.0°C
    • Skin Under temperature: Temp < 34.0°C
    • Skin Positive band: Temp > Set Temp by 1.0°C
    • Skin Negative Band: Temp < Set Temp by 1.0°C
    • Air Over temperature: Temp > 39.0°C
    • Air Under temperature: Temp < 20.0°C
    • Air Positive band: Temp > Set Temp by 1.5°C
    • Air Negative Band: Temp > Set Temp by 3.0°C
    • Heater Failure: Heater connection is failed/damage/faulty
    • System Failure: Fluctuation of voltage supply.
    • Check Sensor position: No proper voltage supply

NIC733 : Infant Radiant Warmer with Fixed Baby Cradle with Microprocessor based temperature controller with 3 mode Skin / Manual / Prewarm
Technical Specification:
Heater Box
  • Consists of Ceramic Infra Red Heater 650Watts,
  • The source box can be swivelled to take X-ray
  • Due to temp. insulated cover on the heater box, its exterior surface remains cool even after long run
  • The construction of the stainless steel reflector and Guard rail is such that the complete cleaning of heater & reflector is possible without any electrical shock hazards
Halogen Examination Lamp (12 Volts, 50 Watts)
  • To Provide accurate assessment of Infant colour and sufficient illumination during procedures
Baby Tray (Stainless Steel)
  • Clear acrylic collapsible side panels
  • Stainless steel baby tray with transparent slot to incorporate the facility of under surface phototherapy
  • Acrylic tray and cushion mattress with head up/down facility
  • Acrylic X-ray tray with X-ray guide for positioning the cassette
  • The design aspects also allow ease of dismantling baby care area during cleaning or fumigation
Essential Attachments
  • Lower Shelves
  • Side Mounted Monitor tray, Pole for Syringe Pump / Infusion Pump
  • S.S. IV Stand.
Micro Computer Based Temp. Controllers
  • To Prove Highest Degree of Accuracy of maintenance of baby’s body Temperature.
Sensors
  • Thermistor type sensor with Accuracy: ± 0.2°C
Alarms
  • Audio alarm mute facility.
  • Mute timing adjustable
Range
  • Skin Mode: 30.0°C to 38.0°C
  • Manual Mode: Vary Heater Power % from 0% to 100% with increment of 5%
  • Time duration (Manual mode): 15 mins (factory default)
  • Prewarm mode: Vary Heater Power % from 0% to 25% with increment of 5%
  • Time duration (Manual mode): 30 mins (factory default)
Displays
  • 1” Bright 7 segment LED’s (3 nos.) for Skin temp.
  • 0.5” Bright 7 segment LED’s (3 nos.) for Set temp.
  • 0.5” Bright 7 segment LED’s (3 nos.) for Heater Power%.
  • Resolution: 0.1°C
Status: On LCD
  • Control Mode
  • Constant Skin temp in ° Fahrenheit.
  • Timer: Down Timer / APGAR Timer
  • Alarm Messages for
    • Skin Over temperature: Temp > 38.0°C
    • Skin Under temperature: Temp < 34.0°C
    • Skin Positive band: Temp > Set Temp by 1.0°C
    • Skin Negative Band: Temp < Set Temp by 1.0°C
    • Heater Failure: Heater connection is failed/damage/faulty
    • System Failure: Fluctuation of voltage supply.
    • Check Sensor position: No proper voltage supply

NIC652 : Infant Radiant Warmer with Detachable Baby Cradle with Microprocessor based temperature controller with 4 mode Skin / Air / Manual / Prewarm
Technical Specification:
Heater Box
  • Consists of Ceramic Infra Red Heater 650Watts,
  • The source box can be swivelled to take X-ray
  • Due to temp. insulated cover on the heater box, its exterior surface remains cool even after long run
  • The construction of the stainless steel reflector and Guard rail is such that the complete cleaning of heater & reflector is possible without any electrical shock hazards
Halogen Examination Lamp (12 Volts, 50 Watts)
  • To Provide accurate assessment of Infant colour and sufficient illumination during procedures
Baby Tray (Stainless Steel)
  • Clear acrylic collapsible side panels
  • Stainless steel baby tray with transparent slot to incorporate the facility of under surface phototherapy
  • Acrylic tray and cushion mattress with head up/down facility
  • Acrylic X-ray tray with X-ray guide for positioning the cassette
  • The design aspects also allow ease of dismantling baby care area during cleaning or fumigation
Essential Attachments
  • Lower Shelves
  • Side Mounted Monitor tray, Pole for Syringe Pump / Infusion Pump
  • S.S. IV Stand.
Micro Computer Based Temp. Controllers
  • To Prove Highest Degree of Accuracy of maintenance of baby’s body Temperature.
Sensors
  • Thermistor type sensor with Accuracy: ± 0.2°C
Alarms
  • Audio alarm mute facility.
  • Mute timing adjustable
Range
  • Skin Mode: 30.0°C to 38.0°C
  • Air Mode: Room temp. 20.0°C to 39.0°C
  • Manual Mode: Vary Heater Power % from 0% to 100% with increment of 5%
  • Time duration (Manual mode): 15 mins (factory default)
  • Prewarm mode: Vary Heater Power % from 0% to 25% with increment of 5%
  • Time duration (Manual mode): 30 mins (factory default)
Displays
  • 1” Bright 7 segment LED’s (3 nos.) for Skin temp.
  • 0.5” Bright 7 segment LED’s (3 nos.) for Set temp.
  • 0.5” Bright 7 segment LED’s (3 nos.) for Heater Power%.
  • 0.5” Bright 7 segment LED’s (3 nos.) for Air temp.
  • Resolution: 0.1°C
Status: On LCD
  • Control Mode
  • Constant Skin temp in ° Fahrenheit.
  • Timer: Down Timer / APGAR Timer
  • Alarm Messages for
    • Skin Over temperature: Temp > 38.0°C
    • Skin Under temperature: Temp < 34.0°C
    • Skin Positive band: Temp > Set Temp by 1.0°C
    • Skin Negative Band: Temp < Set Temp by 1.0°C
    • Air Over temperature: Temp > 39.0°C
    • Air Under temperature: Temp < 20.0°C
    • Air Positive band: Temp > Set Temp by 1.5°C
    • Air Negative Band: Temp > Set Temp by 3.0°C
    • Heater Failure: Heater connection is failed/damage/faulty
    • System Failure: Fluctuation of voltage supply.

NIC653 : Infant Radiant Warmer with Detachable Baby Cradle with Microprocessor based temperature controller with 3 mode Skin / Manual / Prewarm
Technical Specification:
Heater Box
  • Consists of Ceramic Infra Red Heater 650Watts,
  • The source box can be swivelled to take X-ray
  • Due to temp. insulated cover on the heater box, its exterior surface remains cool even after long run
  • The construction of the stainless steel reflector and Guard rail is such that the complete cleaning of heater & reflector is possible without any electrical shock hazards
Halogen Examination Lamp (12 Volts, 50 Watts)
  • To Provide accurate assessment of Infant colour and sufficient illumination during procedures
Baby Tray (Stainless Steel)
  • Clear acrylic collapsible side panels
  • Stainless steel baby tray with transparent slot to incorporate the facility of under surface phototherapy
  • Acrylic tray and cushion mattress with head up/down facility
  • Acrylic X-ray tray with X-ray guide for positioning the cassette
  • The design aspects also allow ease of dismantling baby care area during cleaning or fumigation
Essential Attachments
  • Lower Shelves
  • Side Mounted Monitor tray, Pole for Syringe Pump / Infusion Pump
  • S.S. IV Stand.
Micro Computer Based Temp. Controllers
  • To Prove Highest Degree of Accuracy of maintenance of baby’s body Temperature.
Sensors
  • Thermistor type sensor with Accuracy: ± 0.2°C
Alarms
  • Audio alarm mute facility.
  • Mute timing adjustable
Range
  • Skin Mode: 30.0°C to 38.0°C
  • Manual Mode: Vary Heater Power % from 0% to 100% with increment of 5%
  • Time duration (Manual mode): 15 mins (factory default)
  • Prewarm mode: Vary Heater Power % from 0% to 25% with increment of 5%
  • Time duration (Manual mode): 30 mins (factory default)
Displays
  • 1” Bright 7 segment LED’s (3 nos.) for Skin temp.
  • 0.5” Bright 7 segment LED’s (3 nos.) for Set temp.
  • 0.5” Bright 7 segment LED’s (3 nos.) for Heater Power%.
  • Resolution: 0.1°C
Status: On LCD
  • Control Mode
  • Constant Skin temp in ° Fahrenheit.
  • Timer: Down Timer / APGAR Timer
  • Alarm Messages for
    • Skin Over temperature: Temp > 38.0°C
    • Skin Under temperature: Temp < 34.0°C
    • Skin Positive band: Temp > Set Temp by 1.0°C
    • Skin Negative Band: Temp < Set Temp by 1.0°C
    • Heater Failure: Heater connection is failed/damage/faulty
    • System Failure: Fluctuation of voltage supply.
    • Check Sensor position: No proper voltage supply

NIC642 : Infant Radiant Warmer Stand with Microprocessor based temperature controller with 4 Mode Skin / Air / Manual / Prewarm
Technical Specification:
Heater Box
  • Consists of Ceramic Infra Red Heater 650Watts,
  • The source box can be swivelled to take X-ray
  • Due to temp. insulated cover on the heater box, its exterior surface remains cool even after long run
  • The construction of the stainless steel reflector and Guard rail is such that the complete cleaning of heater & reflector is possible without any electrical shock hazards
Halogen Examination Lamp (12 Volts, 50 Watts)
  • To Provide accurate assessment of Infant colour and sufficient illumination during procedures
Baby Tray (Stainless Steel)
  • Clear acrylic collapsible side panels
  • Stainless steel baby tray with transparent slot to incorporate the facility of under surface phototherapy
  • Acrylic tray and cushion mattress with head up/down facility
  • Acrylic X-ray tray with X-ray guide for positioning the cassette
  • The design aspects also allow ease of dismantling baby care area during cleaning or fumigation
Essential Attachments
  • Side Mounted Monitor tray, Pole for Syringe Pump / Infusion Pump
  • S.S. IV Stand.
Micro Computer Based Temp. Controllers
  • To Prove Highest Degree of Accuracy of maintenance of baby’s body Temperature.
Sensors
  • Thermistor type sensor with Accuracy: ± 0.2°C
Alarms
  • Audio alarm mute facility.
  • Mute timing adjustable
Range
  • Skin Mode: 30.0°C to 38.0°C
  • Air Mode: Room temp. 20.0°C to 39.0°C
  • Manual Mode: Vary Heater Power % from 0% to 100% with increment of 5%
  • Time duration (Manual mode): 15 mins (factory default)
  • Prewarm mode: Vary Heater Power % from 0% to 25% with increment of 5%
  • Time duration (Manual mode): 30 mins (factory default)
Displays
  • 1” Bright 7 segment LED’s (3 nos.) for Skin temp.
  • 0.5” Bright 7 segment LED’s (3 nos.) for Set temp.
  • 0.5” Bright 7 segment LED’s (3 nos.) for Heater Power%.
  • 0.5” Bright 7 segment LED’s (3 nos.) for Air temp.
  • Resolution: 0.1°C
Status: On LCD
  • Control Mode
  • Constant Skin temp in ° Fahrenheit.
  • Timer: Down Timer / APGAR Timer
  • Alarm Messages for
    • Skin Over temperature: Temp > 38.0°C
    • Skin Under temperature: Temp < 34.0°C
    • Skin Positive band: Temp > Set Temp by 1.0°C
    • Skin Negative Band: Temp < Set Temp by 1.0°C
    • Air Over temperature: Temp > 39.0°C
    • Air Under temperature: Temp < 20.0°C
    • Air Positive band: Temp > Set Temp by 1.5°C
    • Air Negative Band: Temp > Set Temp by 3.0°C
    • Heater Failure: Heater connection is failed/damage/faulty
    • System Failure: Fluctuation of voltage supply.
    • Check Sensor position: No proper voltage supply

NIC643 : Infant Radiant Warmer Stand with Microprocessor based temperature controller with 3 Mode Skin / Manual / Prewarm
Technical Specification:
Heater Box
  • Consists of Ceramic Infra Red Heater 650Watts,
  • The source box can be swivelled to take X-ray
  • Due to temp. insulated cover on the heater box, its exterior surface remains cool even after long run
  • The construction of the stainless steel reflector and Guard rail is such that the complete cleaning of heater & reflector is possible without any electrical shock hazards
Halogen Examination Lamp (12 Volts, 50 Watts)
  • To Provide accurate assessment of Infant colour and sufficient illumination during procedures
Baby Tray (Stainless Steel)
  • Clear acrylic collapsible side panels
  • Stainless steel baby tray with transparent slot to incorporate the facility of under surface phototherapy
  • Acrylic tray and cushion mattress with head up/down facility
  • Acrylic X-ray tray with X-ray guide for positioning the cassette
  • The design aspects also allow ease of dismantling baby care area during cleaning or fumigation
Essential Attachments
  • Side Mounted Monitor tray, Pole for Syringe Pump / Infusion Pump
  • S.S. IV Stand.
Micro Computer Based Temp. Controllers
  • To Prove Highest Degree of Accuracy of maintenance of baby’s body Temperature.
Sensors
  • Thermistor type sensor with Accuracy: ± 0.2°C
Alarms
  • Audio alarm mute facility.
  • Mute timing adjustable
Range
  • Skin Mode: 30.0°C to 38.0°C
  • Manual Mode: Vary Heater Power % from 0% to 100% with increment of 5%
  • Time duration (Manual mode): 15 mins (factory default)
  • Prewarm mode: Vary Heater Power % from 0% to 25% with increment of 5%
  • Time duration (Manual mode): 30 mins (factory default)
Displays
  • 1” Bright 7 segment LED’s (3 nos.) for Skin temp.
  • 0.5” Bright 7 segment LED’s (3 nos.) for Set temp.
  • 0.5” Bright 7 segment LED’s (3 nos.) for Heater Power%.
  • Resolution: 0.1°C
Status: On LCD
  • Control Mode
  • Constant Skin temp in ° Fahrenheit.
  • Timer: Down Timer / APGAR Timer
  • Alarm Messages for
    • Skin Over temperature: Temp > 38.0°C
    • Skin Under temperature: Temp < 34.0°C
    • Skin Positive band: Temp > Set Temp by 1.0°C
    • Skin Negative Band: Temp < Set Temp by 1.0°C
    • Heater Failure: Heater connection is failed/damage/faulty
    • System Failure: Fluctuation of voltage supply.
    • Check Sensor position: No proper voltage supply

Categories



What our Clients are Saying

The organic reviews not hoax.


Meet Us At


MEDICA 2024

Hall 10/A74
11th to 14th Nov. 2024
Düsseldorf, Germany.

Arab Health 2025

27th to 30th Jan. 2025
on Concourse Near Ibis Hotel, Dubai World Trade Centre, Dubai, UAE.

FIME 2025

11th to 13th Jun. 2025
Miami Beach Convention Center, Miami Beach, Florida, USA

Become Our Distributor

Let's profit together!
We are looking for distributors in your area.

Infant Radiant Warmer / Open Care System- Manufacture exporters of Infant Radiant Warmer / Open Care System. Trust NET brand for Surgical Instruments, Medical Supplies, Hospital Equipments, Laboratory Products & Goods.

Narang Medical Limited

Narang Tower, 46 Community Centre, Naraina Ph-I, New Delhi - 110028, India.

Call us: +91-11-45554000

Mail Us: NET@narang.com

Associate Sites


© Narang Medical Limited. All Rights Reserved

Narang Medical Reviews

Infant Radiant Warmer

Open Care System

Neonatal Open Care System

Infant Radiant Warmer Manufacturer
