DP2072-E : Portable Ultrasound Machine B/W

Features:

• Thin & Light Notebook design 12 Inch LCD Screen Full digital 80 Elements,
• 800 x 600 resolution
• Rechargeable Lithium Battery : 8800mAhx11.1V
• Dimension : 33x28.9x7cm
• Weight : 4.7kg
• System languages: English, French, Russian, Spanish, Portuguese

Standard Cofiguration :

• With One Convex probe (2.0 - 5MHz) -(used for abdominal, OB & GYN applications)
• One probe connector (optional docking station to enable 2 probe), one key exchange

Specifications:

• Applications : Abdomen, Obsterics, Gynecology, Urology, Pediatric Small organ (Breast, Testes, Thyroid) Cardiac
• Display mode : B,B/B,4B,M,B/M, Local Zoom can be used at real time

Measurements :

• General measurement, GYN & OB measurement,
• Andrology measurement, Cardiac measurement

Probe Options:

• Linear probe (5.5 - 9.0MHz)
• Trans-vaginal probe (5.0 - 8.5MHz)
• Micro-convex probe (4.0 - 7.0MHz)
• Rectal probe

DP2073-C : Ultrasound Machine 2D Color Doppler, Trolley Type

Features:

• 2D Color Doppler Ultrasound, Trolley type
• 21.5’’ LED screen, 1920*1080 pixel

Standard Cofiguration :

• 3 active probe connectors
• WIN 10, Intel i5 processor, 4GB RAM, 256GB SSD
• DICOM 3.0 protocol, available for PACS connection for data transfer

Interfaces :

• 2*USB ports, 1*Video, 1*S-Video, 1*DVI, 1*HDMI, 1*RJ-45

Applications :

• Abdomen, Obstetrics, Gynecology,Cardiac,Urology,
• Small organs, Superficial, Vascular, Pediatrics, Neonatal,
• Muscle, Physical Examination and other inspections and diagnosis.

Specification :

• 2D mode
• Clear image visualization
• Micro imaging technology
• Tissue Harmonic Imaging (THI)
• Trapezoidal Imaging
• Auto-trace
• PW (Pulse Wave)
• CW (Continuous Wave)

Probe Options :

• Convex, linear, trans-vaginal, micro-convex R 15
• phased array, rectal probes.(choose any as per requirement)
• System languages: English, French, Russian, Spanish

DP2075 : Ultrasound Machine 4D/5D Color Doppler - Dual-Screen Trolley Type

Features:

• 4D/5D Color Doppler Ultrasound - OB & GYN, Dual-screen Trolley type
• 21.5’’ LED screen+13.3’’ touch screen,

Standard Configuration :

• WIN 10, Intel i5 processor, 4GB RAM, 256GB SSD
• 4 active probe sockets.
• Rotatable Keyboard : 110 ° Horizontally Adjustable, Module Case with 18cm Vertical Lifting
• Touch Screen: 0°-45° Adjustable Flip

Applications :

• Abdomen, Obstetrics, Gynecology, Cardiac, Urology,
• Small organs, Vascular, Pediatrics, Neonatal,
• Muscle, Physical Examination

Specification :

• Pulse Wave Doppler
• Directional Energy Doppler
• Real-time triple synchronization
• Spatial Composite Imaging
• Tissue Harmonic Imaging
• Trapezoidal Imaging
• 2B/4B Imaging
• System languages: English, French, Russian, Spanish.

Probe Options :

• Convex, linear, trans-vaginal, micro-convex, phased array, rectal, 4D volume probes. (choose any as per requirement)

DP2077 : Ultrasound Machine Color Doppler M Mode Imaging - Trolley Type

Features :

• High End Color Doppler M mode imaging -Trolley type
• A versatile ultrasound model for all departments, ultrasound room, OB&GYN department, radiology, ICU, labour room, cardiology department, emergency room, etc.
• It has a multi-function such as CW, TDI, Anatomic 3M mode for a specific cardiac application, and auto IMT, 3D/4D mode for OB&GYN. Elastography function for radiology to check the tumors etc

Standard Configuration :

• 21.5’’ LED screen+13.3’’ touch screen (1920*1080 pixel)
• WIN7, Intel i5 processor, 8GB RAM, 128GB SSD+1TB, HDD for large patient data storage
• Rotatable Keyboard : 110 ° Horizontally Adjustable, Module Case with 18cm Vertical Lifting
• Touch Screen: 0°-45° Adjustable Flip, 4 active probe sockets

Applications :

• Abdomen, obstetrics, gynecology, heart, urinary system, small organs, superficial, blood vessels, pediatrics, newborns, musculoskeletal

Specification :

• Auto IMT, Auto NT, needle enhancement, CCI (Coherent Contrast imaging), Continuous wave Doppler imaging (CW), Power Doppler imaging (PDI),
• Direct power Doppler imaging (DPDI), Anatomic M, Color M, Tissue Doppler (TDI), Strain rate imaging (SRI), Tissue harmonic imaging(THI),
• Fusion harmonic imaging(FHI), Panoramic imaging , Trapezoidal imaging, free hand 3D, B/C/D Real-time three synchronous imaging.

Language :

• EN/VI/DE/FR/ES/RU/AR/PT/IN

Probe Options :

• Convex, linear, trans-vaginal, micro-convex, phased array (adult and pediatric for options), rectal, 4D volume, hockey stick, bi-plane probes.(choose any as per requirement)

DP2072 : Digital Portable Ultrasound with Led Monitor

• Versatile with unique focus.
• Tissue tracking with quantitative analysis
• Easy mobility
• User friendly
• Efficient

Features:

• Ultra light 6.00 kg. compact unit in carry case
• 12” rotatable LED monitor (0 ~ 30º) with different viewing angles
• Vehicle Power Charger, one key to quickly save image, anti-water keyboard cover
• DICOM 3.0 (option), USB
• 8G Memory Card ›Clips for quick recall (CINE, Still images)
• Advanced image technology; THI, SRA, i-Image, Compound imaging

STANDARD CONFIGURATION : Main unit with one convex probe in carry case

Specifications:

• Applications : Abdomen, Obsterics, Gynecology, Urology, Pediatrics ; Small Organ (breast, testes, thyroid); Cardiac, Peripheral Vascular, Musculo-skeletal Conventional & Superficial
• Display Modes : B, B/B, 4B, M, B/M
• Zoom : 4 Steps

OPTIONAL : Probe connectors, DICOM 3.0,Water-proof keyboard cover, Carrying Case Support PC Printer (HP 1010 / HP 1020 Plus / HP Pro P1102W / HP Pro 200 M251n), TR-9000, Built-in battery

DP2073 : Digital Portable Ultrasound with 4D Color Doppler

Features :

• Light Vibration & noise free probe allows comfort for mother and fetus.
• Smart function with latest technologies like SRA (Speckle Reduction Algorithm), Tissue Harmonic Compound Imaging + i-Image + Measurement & calculation software)
• Advanced 4D technology reveals fetal movement in real time.

• Main unit consist of 19" high resolution contrast LCD Monitor.
• 4 probes connectors
• 3.5 MHz convex probe - 1 pc
• 7.5 MHz linear probe - 1 pc
• 320GB hard disk, DVD-R/W and 6 USB ports
• 4D package: including 2.5MHz-5.3MHz 4D Volume probe, 4D software and 4D hardware module
• i-image : image optimization software

• B, 2B, 4B, B/M, M
• CFM
• PW Mode
• Power Doppler / Directional PD
• Trapezoidal
• Real-time 4D
• Chroma B/PW
• CW (Option)

• Convex probe
• Linear probe
• Transvaginal probe
• Phased array probe
• Micro-Convex probe
• 4D Volume probe

• OB & GYN
• Vascular
• Urology
• Small parts
• Cardiac

• Abdominal
• Obstetrics
• Gynaecology
• Vascular and Small parts
• Pediatric
• Urology
• Musculoskeletal

• 3.5MHz -5.3MHz Convex probe
• 5.0MHz-10.0MHz Linear probe
• 4.0MHz-10.7MHz Linear probe (60mm)
• 4.0MHz-10.0MHz Transvaginal probe
• 4.0MHz-10.7MHz Transvaginal probe
• 2.5MHz-4.0MHz Phased array probe
• 4.0MHz-10.7MHz Micro-Convex probe
• 2.5MHz-6.4MHz Micro-Convex probe (adult Cardiac)
• 3.5MHz-8.0MHz Mico-Convex
• CW
• ECG
• Video Printer : SONY (UPX898MD), PC printer (HP Pro P1102W & HP Pro 200 M251m & Canon selphy cp910)
• PC Printer (any PC printer)
• DICOM 3.0
• i-image : image optimization software
• Biopsy kit : for convex, linear, TV probe
• Foot-switch

DP2073-E : Ultrasound 4D Color Doppler - OB & GYN

Features:

• 19'LED & free arm design, 10.4'LED touch screen, 4 Active transducers ports, 4G RAM, 120G SSD + 500G HDD, Mobile on castors

Standard Configuration :

• Convex probe frequency : 2.0-5.0MHZ
• Linear probe frequency : 6.0-12.0 MHZ
• Trans-vaginal probe frequency : 5.0-9.0MHZ
• 4D volume probe frequency : 2.0-6.0MHz
• Phased array probe frequency : 2.5-4.0MHz

Specifications:

Application areas : Abdominal, OB/GYN, Urology, Cardiac, Vascular, Small Parts, Pediatric, MSK, Imaging Modes 2D, 3D, 4D, Color/PW/CW/Power/Directional Color Power Doppler

Imaging Technology :

4D Imaging, Multi-beam Processing, Tissue Harmonic Imaging, Compound Imaging Technology, Speckle Reduction imaging, Automatic Image Optimization, Trapezoidal imaging

DP2074-E : Ultrasonic Diagnostic System

Features:

• 15 inch LED screen, 2 Active probe ports, Adjustable position, Electronic focus
• Machine size: 740x520x1210mm (LxWxH) NW: 26.6kg, GW: 38.5kg
• Packing size : 81x61x96cm (LxWxH)
• Support Language : CN/EN

Standard Configuration :

• With convex/linear/micro-convex
• Probe frequency: 2.5MHz, 3.5MHz, 4.5MHz, 5.5MHz, 6.5MHz, 7.5MHz, 8.5MHz

Specifications:

• Display mode : B, B+B, 4B, B+M, M
• Measurement : distance, diameter, area, volume, heart rate, gestational age (BPD, GS, CRL, FL, HC, AC, EDD, AFI) and EDD, fetal weight, etc.
• Data Record - date, time, name, gender, age, note for organs
