Veterinary Anesthesia Equipment, Veterinary Anesthesia System With Volume Control, Veterinary Anesthesia Equipment Manufacturer, Veterinary Anesthesia Equipment Suppliers, Veterinary Anesthesia System With Carbon Absorber

Veterinary Anesthesia Equipment

Veterinary Anesthesia System is widely applied to veterinary clinics & hospitals. Model designed for safe, simple and controllable inhalation anesthesia for animals. The Veterinary Anesthesia System provides rapid control of anesthetic depth with little resistance to respiration from high to low acuity, simple to complex cases, small to big animals, like Dogs, Cats, Rabbits, Mice, Birds, etc.

Ask Price

Anesthesia Vaporizer

Ask Price

VAS1010 : Veterinary Anesthesia System with Volume & Pressure Control

Specifications:

10.4” touch screen displays information area, alarm area, monitoring area, and setting area.
Electronic flowmeter, instantly know the fresh gas flow to animals.
Vaporizer with temperature, pressure, flow compensation and self-lock function, keep safety anytime.
Real time pressure-time, flow-time loop oscillogram and high precision ETCO2, O2 concentration detection function included.
Electronic PEEP makes parameter adjustment more precise.
Screen displays manual or mechanical ventilation, keeps safety.
Built-in sensor design with longer use life.
Wide use range for animals within 200KG.
ETCO2 module and Anesthesia Gas Scavenging System (AGSS) are optional.
Built-in backup battery provide the emergency power supply up to 2-3 hours for the unit

Ventilation Modes
IPPV; A/C; PCV; SIMV; SIGH, MANUAL
Ventilator parameter range
Flow meter	O2 (0.1-10L/min) N2O (0.1-10L/min)
Rapid oxygen supply	25L/min-75L/min
Tidal volume(Vt)	0, 20 mL ~ 1500 mL
Frequence(Freq)	1/min ~100/min
Monitored Parameters
Frequence(Freq)	0 /min ~ 100 /min
Tidal volume(Vt)	0 mL ~ 2000 mL
MV	0 L/min ~ 100 L/min
Oxygen concentration	15 % ~ 100 %
Oscillogram
P-T(pressure – time)
F-T(flow – time)
P-V loop (pressure – volume loop)
V-T(volume – time)
ETCO2-T(ETCO2-time)
Working conditions
Gas source	O2, N2O
Pressure	280kPa-600kPa

Ask Price

VAS1015 : Veterinary Anesthesia System with Volume Control

Specifications:

7” screen displays information area, alarm area, monitoring area, and setting area.
High precision mechanical flowmeter, instantly know the fresh gas flow to animals.
Vaporizer with temperature, pressure, flow compensation and self-lock function, keep safety anytime.
Real time pressure-time, flow-time oscillogram
Wide use range for animals within 200KG.
Built-in backup battery provides the emergency power supply up to 2-3 hours for the unit
Anesthesia Gas Scavenging System (AGSS) are optional

Ventilation modes	IPPV; A/C; SIMV; SIGH ,MANUAL
Flow meter	O2 (0-5L/min)
Rapid oxygen supply	25L/min-75L/min
Tidal volume(Vt)	0, 20 mL ~ 1500 mL
Frequence(Freq)	1/min ~100/min
Pressure triggering
sensitivity(PTr)	-20 cmH2O~ 0 cmH2O (Based on PEEP)
Flow trigger sensitivity	0.5 L/min ~ 30 L/min
Apnea Ventilation	OFF,5 s ~ 60 s
Pressure Limit	20 cmH2O~100 cmH2O

Ask Price

VAS1020 : Veterinary Anesthesia System with Carbon Absorber

Specifications:

Pressure Guage and High precision flowmeter ensure accurate adjustment of parameters.
Integrated breathing circuit design, ensure easy operation and keep tidy.
Vaporizer with temperature, pressure, flow compensation and self-lock function
4 casters with 2 individual brakes
Wide range application for animals within 200KG.
For Dogs, Cats, Rabbits, Mice, Birds, etc.

Technical Specification:

Flow meter	O2 (0~5L/min)
Rapid oxygen supply	25L/min-75L/min
Monitoring parameter
Airway pressure	0 cmH2O~100cmH2O
Working condition
Gas source	O2
Pressure	280kPa-600kPa

Ask Price

VAS1025 : Veterinary Anesthesia System

The anesthesia system makes a good performance in operation room with acuity from high to low, applicable for cases from simple to complex. The good performance is based on high security, high accuracy, high stability and accurate monitoring.

Specifications:

The equipment could adapt to different animals and procedures freely.
The high precision of flowmeter instantly lets you know how much fresh gas flow to animals.
Integrated breathing circuit design ensures easy operating and keeps tidy.
Vaporizer with temperature & flow compensation and self-lock function

Technical Specification:

Flow meter	O2 (0~5L/min
Rapid oxygen supply	25L/min-75L/min
Monitoring parameter
Airway pressure	0 cmH2O~100cmH2O
Working condition
Gas source	O2
Pressure	280kPa-600kPa
