Veterinary Ventilator, Veterinary Ventilator Manufacturer, Veterinary Ventilator Suppliers, Animal Ventilator

Features:

7" TFT LCD screen displays the ventilation parameters, alarming information and waveform.
Centered ventilation: The ventilator is precise in both conventional ventilation and advanced ventilation with 3 ventilation modes (IPPV, A/C, SIMV).
Integrated breathing circuit design ensures easy operating and keeps tidy.
Multiple working modes such as volume control and pressure limit, applicable for a wide range of animal.
Multiple parameters monitoring interface makes every parameter clear, letting users know the animal's conditions in all aspects.
Real time pressure-time, flow-time loop graphics are included.
Wide use range including animals within 200 KG.
With built-in backup power source
Three-level alarming system, including visual and sound alarm information.

Technical Specification:

Ventilation modes	IPPV, A/C, SIMV, MANUAL
Ventilator parameter ranges
Tidal volume(Vt)	0, 20 mL ~ 1500 mL
Frequence(Freq)	1 bpm ~ 100 bpm
I/E	2:1~1:6
Pressure triggering sensitivity(PTr)	-20 cmH₂O~ 0 cmH₂O (Based on PEEP)
Flow trigger sensitivity (FTr)	0.5 L/min ~ 30 L/min
SIGH	0(off) 1/100 ~ 5/100
Apnea Ventilation	OFF, 5 s ~ 60 s
Pressure Limit	20 cmH₂O~100 cmH₂O
Monitored Parameters
Frequence(Freq)	0 /min ~ 100 /min
Tidal volume(Vt)	0 mL ~ 2000 mL
MV	0 L/min ~ 100 L/min
Graphical Display
P-T(pressure – time)
F-T(flow – time)
Alarm and Protection
The AC power failure alarm	Power failure or no connection
Internal battery backup low voltage alarm	<±0.3V
No tidal volume	<5mL within 6s
High oxygen concentration alarm	19%-100%
Low oxygen concentration alarm	18%-99%
High Airway pressure alarm	20cmH₂O-100cmH₂O
Low Airway pressure alarm	0cmH₂O-20cmH₂O
High Minute Volume alarm	5L/min-20L/min
Low Minute Volume alarm	1L/min-15L/min
Continuous Pressure alarm	(PEEP+1.5kPa) over 16s
Suffocation warning	5s-60s no spontaneous ventilation
The maximum limited pressure	<12.5 kPa
Fan error	Show on screen
Oxygen deficit	Show on screen
Working Conditions
Gas source	O₂
Pressure	280kPa-600kPa
Voltage	100-240V
Power frequency	50/60Hz
Input Power	60 VA
