Ventilators

NET Ventilator electrically and pneumatically controlled for monitoring and displaying patient's breathing parameter. Used for the saving life of patients(Pediatric /adult) with respiratory failure or insufficient respiration. It is intended for hospital use only.

Feature of ventilator

For adults and children
Multiple modes of ventilation
Colorful LCD display screen
Graphics display of ventilation parameters.

Ask Price

AN340 : ICU Ventilator Venturi Model

Basic Features:

10.4” TFT LCD touch screen displays ventilation parameter, alarm information and oscillogram.
Venturi effect technology ensure the machine works normal without air source.
High Temperature resistance breathing circuit.
Mobile on 4 castors with two brake.

Ventilation mode	IPPV, A/C, PCV, SIMV,SPONT/CPAP, PSV, SIGH, MANUAL
Tidal Volume (Vt)	0,20 - 2000ml
Alarm and protection	14 kinds of alarm and protection functions
Oscillogram	P-T, F-T, P-V loop

Ask Price

AN350 : ICU Ventilator with Pressure and Volume Control

Basic Features:

15” TFT LCD screen displays the Ventilation parameters, Alarming information and Waveform.
Three level alarming system.
With built-in backup power source.
Self-check before running.

Ventilation mode	IPPV, A/C, PCV, SIMV, SPONT/CPAP, PSV, SIGH, MANUAL / APRV / PRVC / DUOLEVEL
Tidal Volume (Vt)	0,20 - 2000mL
Alarm and protection	14 kinds of alarm and protection functions
Oscillogram	P-T, F-T, P-V loop

Ask Price

AN360 : Portable Emergency Ventilator

Standard Features:

Portable Ventilator is used for First-Aid, Ambulance, Emergency situation and patients’ transport in hospital. It is used for both pediatric and adult patients.
Three Power sources : AC, DC and internal Battery ( 8 hours)
Multi Oxygen source : Gas supply on wall / in ambulance / portable 2 litres oxygen Cylinder.
Optional : Carrying Package, 2L Oxygen Aluminum cylinder, Oxygen Bridge Hanging Rack.
Package Dimension : 530*530*280mm,Weight : 13Kg (including all the accessories)

Modes	CMV, A/C, SIMV, SPONT
Tidal Volume	50 - 1200ml
Respiratory Rate	5-60bpm, 1-12bpm for SIMV
FiO2	40% - 100%
Trigger	-10 - 0hpa
Max Minute Volume	≥22L/min
PEEP/PIP	0, 5 - 20hpa, 0 - 60hpa
Over Pressure Relief	72hpa
Sigh	0 - 10 per 100 breath
